Schweitzer Engineering Laboratories SEL-751 - Page 397

Date Code 20170927 Instruction Manual SEL-751 Relay
SET.25
of 78
Date _______________ SEL-751 Settings Sheets
Counters Equations Logic Settings (SET L Command)
SC PRESET VALUE (1–65000) SC09PV :=
SC RESET INPUT (SELOGIC) SC09R :=
SC LOAD PV INPUT (SELOGIC) SC09LD :=
SC CNT UP INPUT (SELOGIC) SC09CU :=
SC CNT DN INPUT (SELOGIC) SC09CD :=
SC PRESET VALUE (1–65000) SC10PV :=
SC RESET INPUT (SELOGIC) SC10R :=
SC LOAD PV INPUT (SELOGIC) SC10LD :=
SC CNT UP INPUT (SELOGIC) SC10CU :=
SC CNT DN INPUT (SELOGIC) SC10CD :=
SC PRESET VALUE (1–65000) SC11PV :=
SC RESET INPUT (SELOGIC) SC11R :=
SC LOAD PV INPUT (SELOGIC) SC11LD :=
SC CNT UP INPUT (SELOGIC) SC11CU :=
SC CNT DN INPUT (SELOGIC) SC11CD :=
SC PRESET VALUE (1–65000) SC12PV :=
SC RESET INPUT (SELOGIC) SC12R :=
SC LOAD PV INPUT (SELOGIC) SC12LD :=
SC CNT UP INPUT (SELOGIC) SC12CU :=
SC CNT DN INPUT (SELOGIC) SC12CD :=
SC PRESET VALUE (1–65000) SC13PV :=
SC RESET INPUT (SELOGIC) SC13R :=
SC LOAD PV INPUT (SELOGIC) SC13LD :=
SC CNT UP INPUT (SELOGIC) SC13CU :=
SC CNT DN INPUT (SELOGIC) SC13CD :=
SC PRESET VALUE (1–65000) SC14PV :=
SC RESET INPUT (SELOGIC) SC14R :=
SC LOAD PV INPUT (SELOGIC) SC14LD :=
SC CNT UP INPUT (SELOGIC) SC14CU :=
SC CNT DN INPUT (SELOGIC) SC14CD :=
SC PRESET VALUE (1–65000) SC15PV :=
SC RESET INPUT (SELOGIC) SC15R :=
SC LOAD PV INPUT (SELOGIC) SC15LD :=
SC CNT UP INPUT (SELOGIC) SC15CU :=
SC CNT DN INPUT (SELOGIC) SC15CD :=
