A.20
SEL-751 Relay Instruction Manual Date Code 20170927
Firmware, ICD, and Manual Versions
Instruction Manual
Appendix F
Revised Table F.7: New Logical Node Extensions, Table F.8: Arc-Flash Detection, and Ta ble F.9: Therm a l
Metering Data Logical Node Class Definition.
Added Table F.10: Demand Metering Statistics Logical Node Class Definition, Table F.11: Circuit Breaker
Supervision (Per-Phase) Logical Node Class Definition, Table F.12: Compatible Logical Nodes With
Extensions, Table F.13: Metering Statistics Logical Node Class Definition, Table F.14: Circuit Breaker Logical
Node Class Definition, and Table F.15: Generic Process I/O Logical Node Class Definition.
Revised Table F.16: Logical Device: PRO (Protection), Table F.17: Logical Device: MET (Metering),
Table F.18: Logical Device: CON (Remote Control), Table F.19: Logical Device: ANN (Annunciation), and
Table F.20: Logical Device: CFG (Configuration).
Appendix J
Updated the definition for the SALARM Relay Word bit.
20130206
Preface
Updated the product labels for the SEL-751.
Section 1
Updated mounting screw size and current/voltage input terminal block information under the Term inal
Connections category of the Specifications.
Updated the time delay setting range for the instantaneous/definite-time overcurrent element.
Updated the pickup and time dial setting ranges for the inverse-time overcurrent elements.
Section 4
Added a note for display points stating that they are updated approximately every two (2) seconds.
Corrected Table 4.63: Entries for the Four Strings for set and clear strings.
Updated Note 3 for Figure 4.1: Instantaneous Overcurrent Element Logic.
Corrected Table 4.77: Settings That Always, Never, or Conditionally Hide a Display Point for the
programmable automation controller setting.
Section 5
Update Table 5.6: Demand Values with new power demand quantities.
Updated the metering screen captures for demand and peak demand functions.
Section 6 Settings Sheets
Revised the hide rules for the 79 element.
Section 9
Updated the footnote for Table 9.1: Event Types with the logic of the GFLT Relay Word bit.
Added explanation to determine fault type and fault location in Event Type.
Added the Event Numbering subsection that explains the procedure for retrieving particular event reports.
Appendix A
Updated for firmware version R105.
Appendix B
Added instructions for upgrading firmware using ACSELERATOR QuickSet.
Appendix E
Revised Reading History Data Using Modbus.
Appendix J
Updated the Relay Word bit definition for GFLT, PHASE_A, PHASE_B, and PHASE_C.
Appendix K
Added new demand and peak demand metering quantities for DNP and Fault date information in Table K.1:
Analog Quantities.
Added a footnote for Relay Word bits RTD through RTD12 in Table K.1: Analog Quantities.
20120903
Preface
Updated product label examples in Product Labels.
Section 1
Updated Specifications.
Table A.8 Instruction Manual Revision History (Sheet 8 of 9)
Revision Date Summary of Revisions
