E.40
SEL-751 Relay Instruction Manual Date Code 20170927
Modbus RTU Communications
Communications Protocol
928 (R) IC MAX A 0 65535 0 1 1028
929 (R) IC MAX TIME ss 0 5999 0 0.01 1029
930 (R) IC MAX TIME mm 0 59 0 1 1030
931 (R) IC MAX TIME hh 0 23 0 1 1031
932 (R) IC MAX DAY dd 1 31 1 1 1032
933 (R) IC MAX DAY mm 1 12 1 1 1033
934 (R) IC MAX DAY yy 2000 9999 2000 1 1034
935 (R) IC MIN A 0 65535 0 1 1035
936 (R) IC MIN TIME ss 0 5999 0 0.01 1036
937 (R) IC MIN TIME mm 0 59 0 1 1037
938 (R) IC MIN TIME hh 0 23 0 1 1038
939 (R) IC MIN DAY dd 1 31 1 1 1039
940 (R) IC MIN DAY mm 1 12 1 1 1040
941 (R) IC MIN DAY yy 2000 9999 2000 1 1041
942 (R) IN MAX A 0 65535 0 1 1042
943 (R) IN MAX TIME ss 0 5999 0 0.01 1043
944 (R) IN MAX TIME mm 0 59 0 1 1044
945 (R) IN MAX TIME hh 0 23 0 1 1045
946 (R) IN MAX DAY dd 1 31 1 1 1046
947 (R) IN MAX DAY mm 1 12 1 1 1047
948 (R) IN MAX DAY yy 2000 9999 2000 1 1048
949 (R) IN MIN A 0 65535 0 1 1049
950 (R) IN MIN TIME ss 0 5999 0 0.01 1050
951 (R) IN MIN TIME mm 0 59 0 1 1051
952 (R) IN MIN TIME hh 0 23 0 1 1052
953 (R) IN MIN DAY dd 1 31 1 1 1053
954 (R) IN MIN DAY mm 1 12 1 1 1054
955 (R) IN MIN DAY yy 2000 9999 2000 1 1055
956 (R) IG MAX A 0 65535 0 1 1056
957 (R) IG MAX TIME ss 0 5999 0 0.01 1057
958 (R) IG MAX TIME mm 0 59 0 1 1058
959 (R) IG MAX TIME hh 0 23 0 1 1059
960 (R) IG MAX DAY dd 1 31 1 1 1060
961 (R) IG MAX DAY mm 1 12 1 1 1061
962 (R) IG MAX DAY yy 2000 9999 2000 1 1062
963 (R) IG MIN A 0 65535 0 1 1063
964 (R) IG MIN TIME ss 0 5999 0 0.01 1064
965 (R) IG MIN TIME mm 0 59 0 1 1065
966 (R) IG MIN TIME hh 0 23 0 1 1066
967 (R) IG MIN DAY dd 1 31 1 1 1067
968 (R) IG MIN DAY mm 1 12 1 1 1068
969 (R) IG MIN DAY yy 2000 9999 2000 1 1069
970 (R) VAB MAX kV 0 65535 0 0.01 1070
971 (R) VAB MX TIM ss 0 5999 0 0.01 1071
972 (R) VAB MX TIM mm 0 59 0 1 1072
Table E.34 Modbus Register Map
a
(Sheet 16 of 38)
Modbus Register
Address
b
Name/Enums Units Min Max Default
Scale
Fac to r
DeviceNet
Parameter
Numbers
