F.30
SEL-751 Relay Instruction Manual Date Code 20170927
IEC 61850 Communications
Logical Nodes
S2TPTOV7 Op.general 59S2T Level 2 VS channel overvoltage element with time delay
S2TPTOV7 Str.general 59S2 Level 2 VS channel overvoltage element pickup
S2TPTOV7 Str.dirGeneral unknown Direction undefined
S2TPTUV8 Op.general 27S2T Level 2 VS channel undervoltage element with time delay
S2TPTUV8 Str.general 27S2 Level 2 VS channel undervoltage element pickup
S2TPTUV8 Str.dirGeneral unknown Direction undefined
T55POPF2 Op.general 55T Power factor trip
T55POPF2 Str.general 55T Power factor trip
T55POPF2 Str.dirGeneral unknown Direction undefined
TOL1PAFD1 Op.general TOL1
c
Arc-Flash Light Input 1 element pickup
TOL1PAFD1 Str.general TOL1
c
Arc-Flash Light Input 1 element pickup
TOL1PAFD1 Str.dirGeneral unknown Direction undefined
TOL2PAFD2 Op.general TOL2
c
Arc-Flash Light Input 2 element pickup
TOL2PAFD2 Str.general TOL2
c
Arc-Flash Light Input 2 element pickup
TOL2PAFD2 Str.dirGeneral unknown Direction undefined
TOL3PAFD3 Op.general TOL3
c
Arc-Flash Light Input 3 element pickup
TOL3PAFD3 Str.general TOL3
c
Arc-Flash Light Input 3 element pickup
TOL3PAFD3 Str.dirGeneral unknown Direction undefined
TOL4PAFD4 Op.general TOL4
c
Arc-Flash Light Input 4 element pickup
TOL4PAFD4 Str.general TOL4
c
Arc-Flash Light Input 4 element pickup
TOL4PAFD4 Str.dirGeneral unknown Direction undefined
TOL5PAFD1 Op.general TOL5
c
Arc-Flash Light Input 5 element pickup
TOL5PAFD1 Str.general TOL5
c
Arc-Flash Light Input 5 element pickup
TOL5PAFD1 Str.dirGeneral unknown Direction undefined
TOL6PAFD2 Op.general TOL6
c
Arc-Flash Light Input 6 element pickup
TOL6PAFD2 Str.general TOL6
c
Arc-Flash Light Input 6 element pickup
TOL6PAFD2 Str.dirGeneral unknown Direction undefined
TOL7PAFD3 Op.general TOL7
c
Arc-Flash Light Input 7 element pickup
TOL7PAFD3 Str.general TOL7
c
Arc-Flash Light Input 7 element pickup
TOL7PAFD3 Str.dirGeneral unknown Direction undefined
TOL8PAFD4 Op.general TOL8
c
Arc-Flash Light Input 8 element pickup
TOL8PAFD4 Str.general TOL8
c
Arc-Flash Light Input 8 element pickup
TOL8PAFD4 Str.dirGeneral unknown Direction undefined
Table F.20 Logical Device: PRO (Protection) (Sheet 12 of 13)
Logical Node Attribute Data Source Comment
