Logical Nodes
MISCGGIO33 Ind01.stVal FREQFZ Synchrophasor bit that asserts if the measured frequency
> ±20 Hz from nominal
MISCGGIO33 Ind02.stVal LINK1 Asserted when a valid link is detected on Port 1 in a single
ethernet option
MISCGGIO33 Ind03.stVal MATHERR SEL
OGIC math error bit
MISCGGIO33 Ind04.stVal HALARM Indication of a diagnostic failure or warning that warrants an
ALARM
MISCGGIO33 Ind05.stVal SALARM Indication of software or user activity that warrants an
ALARM
MISCGGIO33 Ind06.stVal WARNING Relay Word WARNING
MISCGGIO33 Ind07.stVal IRIGOK IRIG-B time synch input data is valid
MISCGGIO33 Ind08.stVal TSOK Time synchronization OK
MISCGGIO33 Ind09.stVal DST Daylight-saving time active
MISCGGIO33 Ind10.stVal LINKA Asserted when a valid link is detected on Port 1A
MISCGGIO33 Ind11.stVal LINKB Asserted when a valid link is detected on Port 1B
MISCGGIO33 Ind12.stVal LINKFAIL Asserted when a valid link is not detected on the active
port(s)
MISCGGIO33 Ind13.stVal PASEL Asserted when Port 1A is active
MISCGGIO33 Ind14.stVal PBSEL Asserted when Port 1B is active
MISCGGIO33 Ind15.stVal COMMLOSS DeviceNet communication failure
MISCGGIO33 Ind16.stVal COMMFLT DeviceNet internal communication failure
MISCGGIO33 Ind17.stVal–Ind32.stVal 0 Reserved for future use
OUTAGGIO2 Ind01.stVal–Ind03.stVal OUT101–OUT103 Digital outputs (OUT101 to OUT103)—Slot A
OUTCGGIO14 Ind01.stVal–Ind08.stVal OUT301–OUT308
b
Digital outputs (OUT301 to OUT308)—Slot C
OUTDGGIO16 Ind01.stVal–Ind08.stVal OUT401–OUT408
b
Digital outputs (OUT401 to OUT408)—Slot D
OUTEGGIO18 Ind01.stVal–Ind08.stVal OUT501–OUT508
b
Digital outputs (OUT501 to OUT508)—Slot E
PBLEDGGIO7 Ind01.stVal PB1A_LED Pushbutton PB1A LED
PBLEDGGIO7 Ind02.stVal PB1B_LED Pushbutton PB1B LED
PBLEDGGIO7 Ind03.stVal PB2A_LED Pushbutton PB2A LED
PBLEDGGIO7 Ind04.stVal PB2B_LED Pushbutton PB2B LED
PBLEDGGIO7 Ind05.stVal PB3A_LED Pushbutton PB3A LED
PBLEDGGIO7 Ind06.stVal PB3B_LED Pushbutton PB3B LED
PBLEDGGIO7 Ind07.stVal PB4A_LED Pushbutton PB4A LED
PBLEDGGIO7 Ind08.stVal PB4B_LED Pushbutton PB4B LED
PBLEDGGIO7 Ind09.stVal PB5A_LED Pushbutton PB5A LED
PBLEDGGIO7 Ind10.stVal PB5B_LED Pushbutton PB5B LED
Table F.23 Logical Device: ANN (Annunciation) (Sheet 4 of 7)
Logical Node Attribute Data Source Comment
