Xerox DocuColor 1632

6/02
2-134
DC1632/2240
8-628, 8-629
Prelaunch Training/Review
Status Indicator RAPs
8-628 Regicon Sample Lateral (A1 Patch-front)
At A1 (OUT) patch detection, the scan position of CYAN color that is the standard for the rest is
incorrect. (Against the MOB SENSOR, the center position of the CYAN pattern is shifted by
±500µm or more.?
NOTE: Status Code not displayed on UI. Machine operation continues.
Procedure
Check the IBT Belt and Drum for a scratch or contamination. The check is OK.
YN
Replace as required.
Perform DC685 Color Registration (ADJ 9.6).
8-629 Regicon Skew (Patch Y)
During A1 Patch detection, skew deviation for Y exceeded tolerance.
NOTE: Machine operation continues. Status Code not displayed on UI. Status Code logged in
History.
Initial Actions
Clean MOB Sensor.
Procedure
Check the IBT Belt and Drum for a scratch or contamination. The check is OK.
YN
Replace as required.
Perform DC685 Color Registration (ADJ 9.6).
