Xerox DocuColor 1632

6/02
2-133
DC1632/2240
8-626, 8-627
Status Indicator RAPs
Prelaunch Training/Review
8-626 Regicon Sample Block (A1 Patch-front)
At A1 (OUT) patch detection, the number of the sample blocks does not reach the specified
number.
NOTE: Status Code not displayed on UI. Machine operation continues.
Procedure
Check the IBT Belt and Drum for a scratch or contamination. The check is OK.
YN
Replace as required.
Perform DC685 Color Registration (ADJ 9.6).
8-627 Regicon Sample Lateral (A1 Patch-rear)
At A1 (IN) patch detection, the Fast Scan scan position of CYAN color that is the standard for
the rest is incorrect. (Against the MOB SENSOR, the center position of the CYAN pattern is
shifted by ±500µm or more.)
NOTE: Status Code not displayed on UI. Machine operation continues.
Procedure
Check the IBT Belt and Drum for a scratch or contamination. The check is OK.
YN
Replace as required.
Perform DC685 Color Registration (ADJ 9.6).
