Status Indicator RAPs
8-624 Regicon Data Overflow (Patch Magnification)
MAG Adjusted Set Point of operation results for each of Y,M,C exceeded the set range (NVM
value: 0~1432).
NOTE: Status Code not displayed on UI. Machine operation continues.
Procedure
Check the IBT Belt and Drum for a scratch or contamination. The check is OK.
YN
Replace as required.
Go to ADJ 9.6 Color Registration dC685.
8-625 Regicon Sample Block (A1 Patch-rear)
At A1 (IN) patch detection, the number of the sample blocks does not reach the specified num-
ber.
NOTE: Status Code not displayed on UI. Machine operation continues.
Procedure
Check the IBT Belt and Drum for a scratch or contamination. The check is OK.
YN
Replace as required.
Perform DC685 Color Registration (ADJ 9.6).
