Status Indicator RAPs
Prelaunch Training/Review
8-622 Regicon Data Overflow (A1 Patch X)
At A1 patch detection, the XSO correction setting value for either Y, M, C, or K exceeds the set-
ting range (NVM value 0 to 472).
NOTE: Status Code not displayed on UI. Machine operation continues.
Procedure
Check the IBT Belt and Drum for a scratch or contamination. The check is OK.
YN
Replace as required.
Perform DC685 Color Registration (ADJ 9.6).
8-623 Regicon Data Overflow (A2 Patch Y)
At A2 patch detection, the YSO correction setting value of either Y, M, C, or K exceeds the set-
ting range (NVM value 0 to 474).
NOTE: Status Code not displayed on UI. Machine operation continues.
Procedure
Check the IBT Belt and Drum for a scratch or contamination. The check is OK.
YN
Replace as required.
Perform DC685 Color Registration (ADJ 9.6).
