6/02
2-394
DC1632/2240
116-382, 116-388
Prelaunch Training/Review
Status Indicator RAPs
116-382 Panel Application Layer Command Error on UI
Controller - MF UI panel: Command error at the application level
A necessary parameter was not sent from the Panel, an length error was detected in a variable
parameter, or the confirmation message was not returned for a specified time after the request
message had been sent to the Panel.
Procedure
Switch power off then on. The problem continues.
YN
Return to service call procedures.
Perform re-installation of the ESS software.
If the problem continues, replace the ESS PWB (PL 13.1).
116-388 No HD that Should Be
The necessary HD was not installed.
Though the system has the configuration requiring the installation of the HD (with Fax), it
detected that the HD was not installed.
Procedure
Switch power off then on. The problem continues.
YN
Return to service call procedures.
Install the HD.
To Next Page
