Xerox DocuColor 1632 Service Manual

6/02
6-13
DC1632/2240
General Procedures and Information
Prelaunch Training/Review
710-xxx DADF NVM List
700-337 Configuration (info. On SEEPROM) - - [P, SP, CSP, CFSP (C)] Set at factory. It allocates bits in the following into P(rinter), F(ax), C(opy), S(can)
respectively and display it in that disjunction. P = 0x01, F = 0x02, C = 0x04, S = 0x08
700-338 Territory (SEEPROM) - 1~4 1=FX, 2=XC, 3=XE, 4=AP
700-339 IOT ROM Major version - - (Auto Setting)
700-340 IOT ROM Minor version - - (Auto Setting)
700-341 IOT ROM Revision version - - (Auto Setting)
700-342 Sys Main ROM Major - - (Auto Setting)
700-343 Sys Main ROM Minor - - (Auto Setting)
700-344 Sys Main ROM Revision - - (Auto Setting)
700-348 IIT ROM Major - - (Auto Setting)
700-349 IIT ROM Minor - - (Auto Setting)
700-350 IIT ROM Revision - - (Auto Setting)
700-351 DADF ROM Major - - (Auto Setting)
700-352 DADF ROM Minor - - (Auto Setting)
700-353 DADF ROM Revision - - (Auto Setting)
700-354 UI Frame ROM Major - - (Auto Setting)
700-355 UI Frame ROM Minor - - (Auto Setting)
700-356 UI Frame ROM Revision - - (Auto Setting)
700-357 UI control ROM Major - - (Auto Setting)
700-358 UI control ROM Minor - - (Auto Setting)
700-359 UI control ROM Revision - - (Auto Setting)
700-360 Product Code (1st digit) - - Alphanumerics (ASCII)
700-361 Product Code (2nd digit) - - Alphanumerics (ASCII)
700-362 Product Code (3rd digit) - - Alphanumerics (ASCII)
700-363 Product Code (4th digit) - - Alphanumerics (ASCII)
700-364 Product Code (5th digit) - - Alphanumerics (ASCII)
700-365 Product Code (6th digit) - - Alphanumerics (ASCII)
700-366 Product Code (7th digit) - - Alphanumerics (ASCII)
700-367 Product Code (8th digit) - - Alphanumerics (ASCII)
700-368 Lpd Buffer Size (Memory Spool) 1MB
(1*1024*1024
)
512*1024~32
*1024*1024
Memory Spool = [512 KB~32 MB] (256 KB interval)
Table 1 Chain 700
Chain-Link Name Default Range Description
Table 2 Chain 710
Chain-Link Name Default Range Description
710-001 ADF Fail Bypass 0 0~1 0 = Bypass ON 1 = Bypass OFF
710-002 JAM Bypass 0 0~1 0 = Bypass ON 1 = Bypass OFF
710-005 Regi Sensor Off to Belt Motor Slow-
down Step (Non CVT Mode)
250 217~283 No. of Steps after the Regi Sensor turned Off and until the Belt Motor started to reduce speed in the Non CVT
Mode. Lead Regi Adjustment Value = 5 +/-5mm
