General Procedures and Information
710-006 DupMode RegiSensor On to Belt Mot.
Slowdown Step (Non CVT Mode)
44 19~69 [Description] = No. of Steps after the Regi Sensor turned On and until the Belt Motor started to reduce speed in
the Non CVT Mode (Reverse & Reverse Output Loop) Regi Roll Loop Adjustment Value at Reverse & Reverse
Output = 4 +/-5mm
710-012 8.5x11"LEF Threshold 2093 1993~2193 Threshold to separated the size detection of 8.5x11"LEF and 8x10"LEF.
710-013 B5SEF/8x10"SEF Switching 0 0~1 0 = B5SEF(FX/XE/AP), 1 = 8x10"SEF(XC)
710-014 11x15"SEF/8K Switching (for AP mar-
ket)
0 0~1 11x15"SEF, 1 = 8K
710-018 FS MAX value 2970 1297~3070 For customized registration of DADF Document Size Detection Decurler
710-019 FS MIN value 2970 1297~3070 For customized registration of DADF Document Size Detection Decurler
710-020 SS MAX value 2100 1297~4418 For customized registration of DADF Document Size Detection Decurler
710-021 SS MIN value 2100 1297~4418 For customized registration of DADF Document Size Detection Decurler
710-022 Document Size 8 3~20 For customized registration of DADF Document Size Detection Decurler
710-023 Document Process Direction 0 0~1 For customized registration of DADF Document Size Detection Decurler
710-024 DADF Doc Size Detection Table 0 0~1 For customized registration of DADF Document Size Detection Decurler
710-025 S Size Side2 Lead Regi Adjust 250 217~283 Side 2 Lead Regi Correction Value of S Size document. Unit = Step (S Size = 131.7mm~158.0mm in Slow
Scan Direction)
710-026 M Size Side2 Lead Regi Adjust 250 217~283 Side 2 Lead Regi Correction Value of M Size document. Unit = Step (M Size = 158.1mm~245.9mm in Slow
Scan Direction)
710-027 L Size Side2 Lead Regi Adjust 250 217~283 Side 2 Lead Regi Correction Value of L Size document. Unit = Step (L Size = 246.0mm~460.0mm in Slow Scan
Direction)
710-800 ADF Static Jam Count Total (No Sensor
Sensed Jam)
0 0~65535 Cumulative Jam Counter (Write not permitted)
710-801 ADF Static Jam Count Since Reset (No
Sensor)
0 0~65535 Cumulative Jam Counter at the previous clearing (Write not permitted)
710-802 ADF Document Input Sensor Static
Jam Count Total
0 0~65535 Cumulative Jam Counter (Write not permitted)
710-803 ADF DocInput SNR Static Jam Count
Since Reset
0 0~65535 Cumulative Jam Counter at the previous clearing (Write not permitted)
710-804 ADF Registration Sensor Static Jam
Count Total
0 0~65535 Cumulative Jam Counter (Write not permitted)
710-805 ADF Regi Sensor Static Jam Count
Since Reset
0 0~65535 Cumulative Jam Counter at the previous clearing (Write not permitted)
710-806 ADF Exit Sensor Static Jam Count Total 0 0~65535 Cumulative Jam Counter (Write not permitted)
710-807 ADF Exit Sensor Static Jam Count
Since Reset
0 0~65535 Cumulative Jam Counter at the previous clearing (Write not permitted)
710-808 ADF Duplex Sensor Static Jam Count
Total
0 0~65535 Cumulative Jam Counter (Write not permitted)
710-809 ADF Duplex Sensor Static Jam Count
Since Reset
0 0~65535 Cumulative Jam Counter at the previous clearing (Write not permitted)
710-810 ADF Regi SNR On NonInvert Dynamic-
Jam Count Total
0 0~65535 Cumulative Jam Counter (Write not permitted)
710-811 ADF Regi SNR On Dynamic Jam Count
Since Reset
0 0~65535 Cumulative Jam Counter at the previous clearing (Write not permitted)
Table 2 Chain 710
Chain-Link Name Default Range Description
