Xerox DocuColor 1632 Service Manual

6/02
6-15
DC1632/2240
General Procedures and Information
Prelaunch Training/Review
715-xxx IIT NVM List
710-812 ADF RegiSNR Off NonInvert Dynamic-
Jam Count Total
0 0~65535 Cumulative Jam Counter (Write not permitted)
710-813 ADF Regi SNR Off Dynamic Jam Count
Since Reset
0 0~65535 Cumulative Jam Counter at the previous clearing (Write not permitted)
710-814 ADF Regi SNR On Dynamic Jam Count
Total (invert)
0 0~65535 Cumulative Jam Counter (Write not permitted)
710-815 ADF RegiSNROn DynamicJamCount
Since Reset (invert)
0 0~65535 Cumulative Jam Counter at the previous clearing (Write not permitted)
710-816 ADF Regi SNR Off Dynamic Jam Count
Total (invert)
0 0~65535 Cumulative Jam Counter (Write not permitted)
710-817 ADF RegiSNROffDynamicJamCount
Since Reset (invert)
0 0~65535 Cumulative Jam Counter at the previous clearing (Write not permitted)
710-818 ADF Exit Sensor On Dynamic Jam
Count Total
0 0~65535 Cumulative Jam Counter (Write not permitted)
710-819 ADF Exit Sensor On Dynamic Jam
Count Since Reset
0 0~65535 Cumulative Jam Counter at the previous clearing (Write not permitted)
710-820 ADF Exit Sensor Off Dynamic Jam
Count Total
0 0~65535 Cumulative Jam Counter (Write not permitted)
710-821 ADF Exit Sensor Off DynamicJam
Count Since Reset
0 0~65535 Cumulative Jam Counter at the previous clearing (Write not permitted)
710-822 Size Mismatch Jam Count Total 0 0~65535 Cumulative Jam Counter (Write not permitted)
710-823 Size Mismatch Jam Count Since Reset 0 0~65535 Cumulative Jam Counter at the previous clearing (Write not permitted)
710-900 Feed Life Count (upper digits) 36 0~65535 Feed Count Replacement Life (Upper digits) (Write not permitted)
710-901 Feed Life Count (lower digits) 40704 0~65535 Feed Count Replacement Life (Lower digits) (Write not permitted)
Table 2 Chain 710
Chain-Link Name Default Range Description
Table 3 Chain 715
Chain-Link Name Default Range Description
715-001 PreIPS Fail Bypass 0 0~1 0 = Fail Bypass is not available, 1 = Fail Bypass is available
715-004 ACS Detection Level 2 0~4 Level 0 (judged from Black and White)~Level 4 (judged from Color)
715-014 PRadjF 120 0~240 Fast Scan Direction Regi Correction Value (Dot) Adjustment at factory. VLSS=PROMVLSS+PRadjF -120 -
Shift Amount
715-015 DADF FS Offset 71 0~150 Fast Scan Offset Value (Dot) when DADF is used. VLSS=PROMVLSS+PRadjF -120 +DADF Offset- Shift
Amount, Adjustment at factory. (DUP Side can be used too)
715-016 Side Registration Shift (-) 0 0~256 For VLSS=PROMVLSS+PRadjF - 120 - Shift Amount and (Dot) Regi adjustments.
715-017 COSAC FS1x5 Filter 0 0~1 0 = OFF, 1 = ON (Moire reduction)
715-018 COSAC Special Feature (Setting range
is TBD)
0 0~2047 bit 0 -> 0 = Normal, 1 = LSWIDE LineSync Active large width bit 1 -> 0 = Normal, 1 = AGOC Cancel, Manual
Setup from NVM-AGCP, AOCP. bit 2 -> 0 = Normal, 1 = Forward revolution output (ONPF=0)
715-051 AOCerr 0 0~255 No. of times the AOC flow has ended in an abnormal way.
715-080 Pshad (1) 148 115~255 Red W-Ref Correction Coefficient Adjustment at factory.
715-081 Pshad (2) 158 115~255 Green W-Ref Correction Coefficient Adjustment at factory.
715-082 Pshad (3) 165 115~255 Blue W-Ref Correction Coefficient Adjustment at factory.
