715-083 Pshad (4) 65 0~127 Red W-Ref Correction Coefficient P Paper Adjustment at factory.
715-084 Pshad (5) 72 0~127 Green W-Ref Correction Coefficient P Paper Adjustment at factory.
715-085 Pshad (6) 69 0~127 Blue W-Ref Correction Coefficient P Paper Adjustment at factory.
715-113 A6/Postcard Detection 0 0~1 0 = A6 Document, 1 = Postcard Document (XC 0 = Postcard, 1 = A6)
715-114 A4S/8.5in Detection 1 0 0~1 0 = A4 Fixed (Other than XC), Letter Fixed (XC), 1 = Can be changed by Area Switching 2
715-115 A4S/8.5in Detection 2 3 0~6 0 = 210mm(A4S)~6 = 216mm(8.5")
715-116 Original detection table for special
paper
0 0~2 0 = Do not use special table 1 = A Series (A4L when APS is Off, and A3S when APS is On) 2 = Inch Series
(Letter LEF when APS is Off, and 11x17" when APS is On)
715-128 DADF FS Offset (side 2) 71 01~50 Fast Scan Offset value (Dot) on IPS at DADF DUP Side 2. VLSS=PROMVLSS+PRadjF - 50 +DADF Offset Side
2 Adjustment at factory.
715-138 Document Size Detection 0 0~1 0 = Detection by 4 Registers, 1 = Detection by 3 Registers (Contamination Countermeasure)
715-139 B5/8x10" Detection 0 0~1 B5/8x10" Switching (Default 0 = B5 Detection, 1 = 8x10" Detection)
715-140 8K Detection 0 0~1 8K detection specification (Default 0 = Do not detect, 1 = Detect)
715-141 8.5x13"/8.5x14" Detection 0 0~1 8.5x13"/8.5x14" Detection Switching Specification in AP/XE markets.
715-142 NutAngleF 990 0~1980 Front NUT Revolution Angle (990~1980 = Right revolution angle, 0~990 = Left revolution angle)
715-143 NutAngleR 990 0~1980 Rear NUT Revolution Angle (990~1980 = Right revolution angle, 0~990 = Left revolution angle)
715-200 External Area of FS Sampling 255 0~511 Speed Priority AE/Fast Scan direction undetected area
715-204 Maximum Sampling Value of Back-
ground color
90 0~255 Speed Priority AE/Sampling Upper Limit/BMAX
715-205 Initial Background color Value 0 0~255 Speed Priority AE/Background level initial value/INIT
715-208 Line to Fix Variation 48 0~255 Speed Priority AE/Slow Scan variation fixed position/NCON
715-212 Background Color Suppression mode
for BW
2 0~2 Speed Priority AE/Suppression Mode Setup in B/W 0 = Register, 1 = Fixed, 2 = Vary
715-213 Background Color Suppression mode
for Color
0 0~2 Speed Priority AE/Suppression Mode Setup in Color 0 = Register, 1 = Fixed, 2 = Vary
715-214 Undercolor Data for BW 0 0~255 Speed Priority AE/Fixed background color data in B/W Register Mode
715-215 Undercolor Data for Color 0 0~255 Speed Priority AE/Fixed background color data in Color Register Mode
715-218 Gamma Data for BW 1 0~2 AE GAMMA Data in B/W mode 0 = GMD=2, 1 = GMD=3, 2 = GMD=5
715-219 Gamma Data for Color 1 0~2 AE GAMMA Data in Color mode 0 = GMD=2, 1 = GMD=3, 2 = GMD=5
715-220 Color Balance Default = Y/Low density 4 0~8 Default Color Balance Adjustment Level Y Color Low density
715-221 Color Balance Default = Y/Medium
density
4 0~8 Default Color Balance Adjustment Level Y Color Medium density
715-222 Color Balance Default = Y/High density 4 0~8 Default Color Balance Adjustment Level Y Color High density
715-223 Color Balance Default = M/Low density 4 0~8 Default Color Balance Adjustment Level M Color Low density
715-224 Color Balance Default = M/Medium
density
4 0~8 Default Color Balance Adjustment Level M Color Medium density
715-225 Color Balance Default = M/High den-
sity
4 0~8 Default Color Balance Adjustment Level M Color High density
715-226 Color Balance Default = C/Low density 4 0~8 Default Color Balance Adjustment Level C Color Low density
715-227 Color Balance Default = C/Medium
density
4 0~8 Default Color Balance Adjustment Level C Color Medium density
715-228 Color Balance Default = C/High density 4 0~8 Default Color Balance Adjustment Level C Color High density
Table 3 Chain 715
