Xerox DocuColor 1632 Service Manual

6/02
6-17
DC1632/2240
General Procedures and Information
Prelaunch Training/Review
715-229 Color Balance Default = K/Low density 4 0~8 Default Color Balance Adjustment Level K Color Low density
715-230 Color Balance Default = K/Medium
density
4 0~8 Default Color Balance Adjustment Level K Color Medium density
715-231 Color Balance Default = K/high density 4 0~8 Default Color Balance Adjustment Level K Color High density
715-232 Photo reproduction level 1 0~2 0 = Above Text, 1 = Normal, 2 = Above Photo
715-233 Text/Photo separation level 2 0~4 0 = Above Text, 1 = Slightly above text, 2 = Normal, 3 = Slightly above photo, 4 = Above Photo
715-234 FS Magnification Adjustment 50 0~100 Magnification fine adjustment in Fast Scan direction. Specified in units between range of 0~100. The value indi-
cates the magnification adjustment with 0= -5%, 50= 0% and 100= 5% at ±5% (0.1% unit) (Adjustment at fac-
tory.)
715-237 Normal Density Text (BW Copy) 128 0~256 B/W COPY Text Normal Density Adjustment
715-238 High Density Text (BW Copy) 128 0~256 B/W COPY Text Darker 3 Density Adjustment
715-239 Normal Density Text (Scan) 128 0~256 Scan Text Normal Density Adjustment
715-240 High Density Text (Scan) 128 0~256 Scan Text Darker 3 Density Adjustment
715-241 SS Not Detect Area for Platen model
(Real Time AE)
38 0~65535 Slow Scan Non-detection area Setup value at Real Time AE for platen model.
715-242 SS Not Detect Area for DADF model
DADF mode (Real Time AE)
38 0~65535 Slow Scan Non-detection area Setup value at Real Time AE for DADF model platen job.
715-243 SS Not Detect Area for DADF model
Platen mode (Real Time AE)
38 0~65535 Slow Scan Non-detection area Setup value at Real Time AE for DADF model DADF job.
715-244 B/W-Offset for Text/Image Platen mode
(Real Time AE)
10 0~255 For AE OFFSET data Platen text/photo in B/W model
715-245 B/W-Offset for Text Platen mode (Real
Time AE)
10 0~255 For AE OFFSET data Platen text in B/W model
715-246 B/W-Offset for Map Platen mode (Real
Time AE)
10 0~255 For AE OFFSET data Platen map in B/W model
715-247 B/W-Offset for Text/Image DADF Single
Side mode (Real Time AE)
13 0~255 For AE OFFSET data DADF Single Side Document text/photo in B/W model
715-248 B/W-Offset for Text DADF Single Side
mode(Real Time AE)
15 0~255 For AE OFFSET data DADF Single Side Document text in B/W model
715-249 B/W-Offset for Map DADF Single Side
mode Real Time AE)
13 0~255 For AE OFFSET data DADF Single Side Document map in B/W model
715-250 B/W-Offset for Text/Image DADF
Duplex Side mode (Real Time AE)
17 0~255 For AE OFFSET data DADF Duplex Side Document text/photo in B/W model
715-251 B/W-Offset for Text DADF Duplex Side
mode (Real Time AE)
17 0~255 For AE OFFSET data DADF Duplex Side Document text in B/W model
715-252 B/W-Offset for Map DADF Duplex Side
mode (Real Time AE)
17 0~255 For AE OFFSET data DADF Duplex Side Document map in B/W model
715-253 Color-Offset for Text/Image Platen
mode (Real Time AE)
15 0~255 For AE OFFSET data Platen text/photo in Color model
715-254 Color-Offset for Text Platen mode (Real
Time AE)
15 0~255 For AE OFFSET data Platen text in Color model
715-255 Color-Offset for Text Platen mode (Real
Time AE)
15 0~255 For AE OFFSET data Platen map in Color model
Table 3 Chain 715
Chain-Link Name Default Range Description
