Xerox DocuColor 1632 Service Manual

6/02
6-18
DC1632/2240
Prelaunch Training/Review
General Procedures and Information
715-256 Color-Offset for Text/Image DADF Sin-
gle Side mode (Real Time AE)
17 0~255 For AE OFFSET data DADF Single Side Document text/photo in Color model
715-257 Color-Offset for Text DADF Single Side
mode (Real Time AE)
18 0~255 For AE OFFSET data DADF Single Side Document text in Color model
715-258 Color-Offset for Map DADF Single Side
mode (Real Time AE)
17 0~255 For AE OFFSET data DADF Single Side Document map in Color model
715-259 Color-Offset for Text/Image DADF
Duplex Side mode (Real Time AE)
17 0~255 For AE OFFSET data DADF Duplex Side Document text/photo in Color model
715-260 Color-Offset for Text DADF Duplex Side
mode (Real Time AE)
18 0~255 For AE OFFSET data DADF Duplex Side Document text in Color model
715-261 Color-Offset for Map DADF Duplex
Side mode (Real Time AE)
17 0~255 For AE OFFSET data DADF Duplex Side Document map in Color model
715-300 IIT Fail Bypass 0 0~1 0 = Fail Bypass is not available, 1 = Fail Bypass is available
715-301 SS Registration Adjustment 100 16~184 Slow Scan Direction Regi Correction Value (0.036mm/step) Adjustment at factory.
715-302 SS Magnification Adjustment 50 44~56 Slow Scan direction Magnification Correction Value (0.1%/step) Adjustment at factory.
715-400 Platen/ADF 0 0~1 0 = Platen model 1 = ADF model Adjustment at factory.
715-401 AGOC Timing 15 0~29 Time between Power ON/Energy Saver recovery and AGOC (min.) (0 = Timer not available)
715-800 lIISS/ADF Communication Fail Count
Overall Total
0 0~65535 Cumulative Fail Counter (Write not permitted)
715-801 IISS/ADF Communication Fail Count
Since Reset
0 0~65535 Cumulative Fail Counter at the previous clearing (Write not permitted)
715-802 lIISS RAM CHECK Failure Count Over-
all Total
0 0~65535 Cumulative Fail Counter (Write not permitted)
715-803 IISS RAM CHECK Failure Count Since
Reset
0 0~65535 Cumulative Fail Counter at the previous clearing (Write not permitted)
715-804 EEPROM Failure Count Overall Total 0 0~65535 Cumulative Fail Counter (Write not permitted)
715-805 EEPROM Failure Count Since Reset 0 0~65535 Cumulative Fail Counter at the previous clearing (Write not permitted)
715-806 Fan Failure Count Overall Total 0 0~65535 Cumulative Fail Counter (Write not permitted)
715-807 Fan Failure Count Since Reset 0 0~065535 Cumulative Fail Counter at the previous clearing (Write not permitted)
715-808 Scan Carriage Position Fail Count
Overall Total
0 0~65535 Cumulative Fail Counter (Write not permitted)
715-809 Scan Carriage Position Fail Count
Since Reset
0 0~65535 Cumulative Fail Counter at the previous clearing (Write not permitted)
715-810 Scan CRG Init Regi SNR Fail Count
Overall Total
0 0~65535 Cumulative Fail Counter (Write not permitted)
715-811 Scan CRG Init Regi Sensor Fail Count
Since Reset
0 0~65535 Cumulative Fail Counter at the previous clearing (Write not permitted)
715-812 PreIPS (X) Recognition Fail Count
Overall Total
0 0~65535 Cumulative Fail Counter (Write not permitted)
715-813 PreIPS (X) Recognition Fail Count
Since Reset
0 0~65535 Cumulative Fail Counter at the previous clearing (Write not permitted)
715-814 Lamp Failure Count Overall Total 0 0~65535 Cumulative Fail Counter (Write not permitted)
715-815 Lamp Failure Count Since Reset 0 0~65535 Cumulative Fail Counter at the previous clearing (Write not permitted)
Table 3 Chain 715
Chain-Link Name Default Range Description
