6/02
6-26
DC1632/2240
Prelaunch Training/Review
General Procedures and Information
744--xxx User NVM List
742-100 MAIN FEED START TIMING 3TM-3 38 0~83
(1bit= 1.31136ms)
Adjust the Time between the MAIN FEED Starts and the PRE T/A (810~1310ms).
742-101 MAIN FEED START TIMING TTM-2 38 0~83
(1bit= 1.31136ms)
Adjust the Time between the MAIN FEED Starts and the PRE T/A (780~1280ms).
742-102 MAIN FEED START TIMING TTM-3 38 0~83
(1bit= 1.31136ms)
Adjust the Time between the MAIN FEED Starts and the PRE T/A (1410~1910ms).
742-103 Select A/B or INCH (SMH Auto Detect) 0 0~1 0 = A/B series, 1 = Inch series
742-104 Select 2ndBTR Cleaning (SMH Auto
Detect)
1 0~1 0 = No, 1 = Yes
742-105 RegiLoopLengthAjust (DUP) (a sheet of
paper)
41 0~81
(1bit= 2.4462ms)
Lead Regi Length Adjustment (P Speed) from Dup (Feeding Length Letter-LEF and longer)Default=157ms
742-106 PRE T/A START TIMING 3TM-1 (Half) 37 0~58
(1bit= 4.8924ms)
Adjusts the Time between PRE T/A Starts and Standard Signal (IOT) (303~803ms)
742-107 PRE T/A START TIMING 3TM-2 (Half) 37 0~58
(1bit= 4.8924ms)
Adjusts the Time between PRE T/A Starts and Standard Signal (IOT) (365~865ms)
742-108 PRE T/A START TIMING 3TM-3 (Half) 37 0~58
(1bit= 4.8924ms)
Adjusts the Time between PRE T/A Starts and Standard Signal (IOT) (429~929ms)
742-109 PRE T/A START TIMING TTM-2 (Half) 37 0~58
(1bit= 4.8924ms)
Adjusts the Time between PRE T/A Starts and Standard Signal (IOT) (457~957ms)
742-110 PRE T/A START TIMING TTM-3 (Half) 37 0~58
(1bit= 4.8924ms)
Adjusts the Time between PRE T/A Starts and Standard Signal (IOT) (431~931ms)
742-111 MAIN FEED START TIMING 3TM-1
(Half)
10 0~22
(1bit= 4.8924ms)
Adjust the Time between the MAIN FEED Starts and the PRE T/A (330~830ms).
742-112 MAIN FEED START TIMING 3TM-2
(Half)
10 0~22
(1bit= 4.8924ms)
Adjust the Time between the MAIN FEED Starts and the PRE T/A (570~1070ms).
742-113 MAIN FEED START TIMING 3TM-3
(Half)
10 0~22
(1bit= 4.8924ms)
Adjust the Time between the MAIN FEED Starts and the PRE T/A (810~1310ms).
742-114 MAIN FEED START TIMING TTM-2
(Half)
10 0~22
(1bit= 4.8924ms)
Adjust the Time between the MAIN FEED Starts and the PRE T/A (780~1280ms).
742-115 MAIN FEED START TIMING TTM-3
(Half)
10 0~22
(1bit= 4.8924ms)
Adjust the Time between the MAIN FEED Starts and the PRE T/A (1410~1910ms).
Table 8 Chain 742
Chain-Link Name Default Range Description
Table 9 Chain 744
Chain-Link Name Default Range Description
744-001 STS-1 CONT TEMP in Low PWR Mode 80 0~160
(1 bit=1 deg. C)
Main-Lamp temperature control in Low-Power Mode. Setting the default as 0 Degrees Celsius is same as
Fuser-Off. It is necessary for high temperature for recovery Time Claim.
744-002 STS-2 CONT TEMP in Low PWR Mode 80 0~160
(1 bit=1 deg. C)
Sub-Lamp temperature control in Low-Power Mode. Setting the default as 0 Degrees Celsius is same as Fuser-
Off. It is necessary for high temperature for recovery Time Claim.
744-003 UM status by High Temperature Error
Detection
0 0~2 0 (Normal) or 1 (STS-1 High Temperature Error Detection) or 2 (STS-2 High Temperature Error Detection).UM
Status occurs when either STS-1 or STS-2 High Temperature Error Detection is detected. Once this occurs, UM
cannot be canceled unless this NVM value is changed to 0 by entering the Diag Mode in the Interlock-Open sta-
tus of the M/C-Front Cover.
