6/02
6-25
DC1632/2240
General Procedures and Information
Prelaunch Training/Review
742-071 MAIN FEED START TIMING 3TM-3 20 0~44
(1bit= 10ms)
Adjust the Time between the MAIN FEED Starts and the PRE T/A (810~1310ms).
742-072 MAIN FEED START TIMING TTM-1 20 0~44
(1bit= 10ms)
Adjust the Time between the MAIN FEED Starts and the PRE T/A (330~830ms).
742-073 MAIN FEED START TIMING TTM-2 20 0~44
(1bit= 10ms)
Adjust the Time between the MAIN FEED Starts and the PRE T/A (780~1280ms).
742-074 MAIN FEED START TIMING TTM-3 20 0~44
(1bit= 10ms)
Adjust the Time between the MAIN FEED Starts and the PRE T/A (1410~1910ms).
742-075 MAIN FEED START TIMING 1TM-1 25 0~50
(1bit= 10ms)
Adjust the Time between the MAIN FEED Starts and the PRE T/A (330~830ms).Default=580ms
742-076 ADJUST SIDE REGI 2Tray 20 0~50
(1bit= 0.211mm)
SIDE REGI adjustment of 2TRAY
742-077 ADJUST SIDE REGI 3Tray 20 0~50
(1bit= 0.211mm)
SIDE REGI adjustment of 3TRAY
742-078 ADJUST SIDE REGI 4Tray 20 0~50
(1bit= 0.211mm)
SIDE REGI adjustment of 4TRAY
742-079 ADJUST SIDE REGI TrayModuleAll 25 0~50
(1bit= 0.211mm)
SIDE REGI adjustment of 2, 3, 4TRAY (Batch adjustment)
742-080 PAPER THE REST 3TM-1 0 0~4000 Saves the Cumulative LIFT UP Time from TRAY insertion (For remaining detection calculation as=A).
742-081 PAPER THE REST 3TM-2 0 0~4000 Saves the Cumulative LIFT UP Time from TRAY insertion (For remaining detection calculation as=A).
742-082 PAPER THE REST 3TM-3 0 0~4000 Saves the Cumulative LIFT UP Time from TRAY insertion (For remaining detection calculation as=A).
742-083 PAPER THE REST TTM-1 0 0~4000 Saves the Cumulative LIFT UP Time from TRAY insertion (For remaining detection calculation as=A).
742-084 PAPER THE REST TTM-2 0 0~12000 Saves the Cumulative LIFT UP Time from TRAY insertion (For remaining detection calculation as=A).
742-085 PAPER THE REST TTM-3 0 0~15000 Saves the Cumulative LIFT UP Time from TRAY insertion (For remaining detection calculation as=A).
742-086 PAPER THE REST 1TM-1 0 0~4000 Saves the Cumulative LIFT UP Time from TRAY insertion (For remaining detection calculation as=A).
742-087 OCT Condition 1 0~1 0 = Not available, 1 = Available
742-088 Dup On Timing (From Regi Start) 20 0~40
(1bit= 1.31136ms)
Synchronize adjustment to be same as the Regi Clutch at Regi Start (Double Speed)
742-089 OCT Start Timing (Home) 17 0~112
(1bit= 1.31136ms)
OCT (Home) Start Timing Adjustment (Double Speed)
742-093 PRE T/A START TIMING 3TM-1 139 0~215
(1bit= 1.31136ms)
Adjusts the Time between PRE T/A Starts and Standard Signal (IOT) (303~803ms)
742-094 PRE T/A START TIMING 3TM-2 139 0~215
(1bit= 1.31136ms)
Adjusts the Time between PRE T/A Starts and Standard Signal (IOT) (365~865ms)
742-095 PRE T/A START TIMING 3TM-3 139 0~215
(1bit= 1.31136ms)
Adjusts the Time between PRE T/A Starts and Standard Signal (IOT) (429~929ms)
742-096 PRE T/A START TIMING TTM-2 139 0~215
(1bit= 1.31136ms)
Adjusts the Time between PRE T/A Starts and Standard Signal (IOT) (457~957ms)
742-097 PRE T/A START TIMING TTM-3 139 0~215
(1bit= 1.31136ms)
Adjusts the Time between PRE T/A Starts and Standard Signal (IOT) (431~931ms)
742-098 MAIN FEED START TIMING 3TM-1 38 0~83
(1bit= 1.31136ms)
Adjust the Time between the MAIN FEED Starts and the PRE T/A (330~830ms).
742-099 MAIN FEED START TIMING 3TM-2 38 0~83
(1bit= 1.31136ms)
Adjust the Time between the MAIN FEED Starts and the PRE T/A (570~1070ms).
Table 8 Chain 742
Chain-Link Name Default Range Description
