6/02
6-24
DC1632/2240
Prelaunch Training/Review
General Procedures and Information
742-048 OHP Sheet Sensing Condition 1 0~1 Transparency Detection 1 = Detect 0 = Does not detect
742-049 Tray 5 Side Guide Min Data 972 927~1017
(1bit= 1mm)
Saves the Tray 5 Size Detection Min Value
742-050 Tray 5 Side Guide Max Data 52 7~97 (1bit= 1mm) Saves the Tray 5 Size Detection Max Value
742-051 FEED START TIMING 1Tray 82
(450ms)
0~163
(1bit= 2.4462ms)
Adjusts the time between Pitch (Standard Signal IOT) and FEED Starts (250~650ms).
742-052 FEED START TIMING 1Tray 82 0~163
(1bit= 1.31136ms)
742-053 ADJUST SIDE REGI 1Tray 22 0~50
(1bit= 0.211mm)
SIDE REGI Adjustment for each TRAY
742-054 PAPER THE REST 1Tray 0 0~4000 Saves the Cumulative LIFT UP Time from TRAY insertion (For remaining detection calculation as=A).
742-055 PRE T/A START TIMING 3TM-1 74 0~115
(1bit= 2.4462ms)
Adjusts the Time between PRE T/A Starts and Standard Signal (IOT) (303~803ms)
742-056 PRE T/A START TIMING 3TM-2 74 0~115
(1bit= 2.4462ms)
Adjusts the Time between PRE T/A Starts and Standard Signal (IOT) (365~865ms)
742-057 PRE T/A START TIMING 3TM-3 74 0~115
(1bit= 2.4462ms)
Adjusts the Time between PRE T/A Starts and Standard Signal (IOT) (429~929ms)
742-058 PRE T/A START TIMING TTM-1 10 0~16
(1bit= 2.4462ms)
Adjusts the Time between PRE T/A Starts and Standard Signal (IOT)
742-059 PRE T/A START TIMING TTM-2 74 0~115
(1bit= 2.4462ms)
Adjusts the Time between PRE T/A Starts and Standard Signal (IOT) (457~957ms)
742-060 PRE T/A START TIMING TTM-3 74 0~115
(1bit= 2.4462ms)
Adjusts the Time between PRE T/A Starts and Standard Signal (IOT) (431~931ms)
742-061 PRE T/A START TIMING 1TM-1 102 0~204
(1bit= 2.4462ms)
Adjusts the Time between PRE T/A Starts and Standard Signal (IOT) (303~803ms). Default=553ms
742-062 ADJUST PRE FEED POSITION 3TM-1 0 0~40
(1bit= 10ms)
Adjust the Time between the FEED OUT SNR ON and the FEED MOT OFF (0~400ms).
742-063 ADJUST PRE FEED POSITION 3TM-2 0 0~40
(1bit= 10ms)
Adjust the Time between the FEED OUT SNR ON and the FEED MOT OFF (0~400ms).
742-064 ADJUST PRE FEED POSITION 3TM-3 0 0~40
(1bit= 10ms)
Adjust the Time between the FEED OUT SNR ON and the FEED MOT OFF (0~400ms).
742-065 ADJUST PRE FEED POSITION TTM-1 0 0~40
(1bit= 10ms)
Adjust the Time between the FEED OUT SNR ON and the FEED MOT OFF (0~400ms).
742-066 ADJUST PRE FEED POSITION TTM-2 0 0~40
(1bit= 10ms)
Adjust the Time between the FEED OUT SNR ON and the FEED MOT OFF (0~400ms).
742-067 ADJUST PRE FEED POSITION TTM-3 37 10~50
(1bit= 10ms)
Adjust the Time between the FEED OUT SNR ON and the FEED MOT OFF (100~500ms). Default=370ms
742-068 ADJUST PRE FEED POSITION 1TM-1 0 0~40
(1bit= 10ms)
Adjust the Time between the FEED OUT SNR ON and the FEED MOT OFF (0~400ms).
742-069 MAIN FEED START TIMING 3TM-1 20 0~44
(1bit= 10ms)
Adjust the Time between the MAIN FEED Starts and the PRE T/A (330~830ms).
742-070 MAIN FEED START TIMING 3TM-2 20 0~44
(1bit= 10ms)
Adjust the Time between the MAIN FEED Starts and the PRE T/A (570~1070ms).
Table 8 Chain 742
Chain-Link Name Default Range Description
