General Procedures and Information
Prelaunch Training/Review
742-021 Feed Start Timing (MSI) (MF) 150 0~300 (1bit=
1.31136ms)
Feed Start Timing Adjustment from Pitch (Double Speed) (100~500ms)
742-022 Feed Motor Off Timing 10 0~35
(1bit= 10ms)
Feed Motor Off Timing Adjustment from T/A Nip
742-023 Regi Clutch Off Timing 41 0~81
(1bit= 2.4462ms)
Adjusts the time between the paper rear edge has passes the Regi Sensor and the Regi Clutch Turns Off (P
Speed) (90~290ms). Default=190ms
742-024 Regi Clutch Off Timing (MF) 76 0~152
(1bit= 1.31136ms)
Adjusts the time between the paper rear edge has passes the Regi Sensor and the Regi Clutch Turns Off (Dou-
ble Speed)
742-025 ADJUST SIDE REGI (ALL) 25 0~50
(1bit= 0.211mm)
Side Regi Adjustment (ALL, Offset value)
742-026 ADJUST SIDE REGI (MSI) 20 0~50
(1bit= 0.211mm)
Side Regi Adjustment (MSI)
742-027 ADJUST SIDE REGI (Dup) 22 0~50
(1bit= 0.211mm)
Side Regi Adjustment (Dup)
742-028 ADJUST LEAD REGI (ALL) 20 0~40
(1bit= 0.2544mm)
Lead Regi Adjustment (ALL, Offset value)
742-029 ADJUST LEAD REGI (Tray) 12 0~40
(1bit= 0.2544mm)
Lead Regi Adjustment (P Speed) from Tray
742-030 ADJUST LEAD REGI (Tray) 20 0~40
(1bit= 0.2544mm)
Lead Regi Adjustment (Double Speed) from Tray
742-031 ADJUST LEAD REGI (MSI) (Standard
Paper)
11 0~40
(1bit= 0.2544mm)
Lead Regi Adjustment (P Speed) Standard Paper from Tray 5
742-032 ADJUST LEAD REGI (MSI) (Standard
Paper)
20 0~40
(1bit= 0.2544mm)
Lead Regi Adjustment (Double Speed) Standard Paper from MSI
742-033 ADJUST LEAD REGI (MSI) (Heavy1) 20 0~40
(1bit= 0.2544mm)
Lead Regi Adjustment (P Speed) Heavy Weight Paper 1 from Tray 5
742-034 ADJUST LEAD REGI (MSI) (Heavy2) 20 0~40
(1bit= 0.2544mm)
Lead Regi Adjustment (Half Speed) Heavy Weight Paper 2 from Tray 5
742-035 ADJUST LEAD REGI (MSI) (Heavy
Paper1)
20 0~40
(1bit= 0.2544mm)
Lead Regi Adjustment (Half Speed) Heavy Weight Paper 1 from Tray 5
742-036 ADJUST LEAD REGI (MSI) (Heavy
Paper2)
20 0~40
(1bit= 0.2544mm)
Lead Regi Adjustment (Half Speed) Heavy Weight Paper 2 from Tray 5
742-037 ADJUST LEAD REGI (Dup) 11 0~40
(1bit= 0.2544mm)
Lead Regi Adjustment (P Speed) (Side2)
742-038 ADJUST LEAD REGI (Dup) 20 0~40
(1bit= 0.2544mm)
Lead Regi Adjustment (Double Speed) (Side2)
742-039 Jam Bypass 0 0~255 0 = Normal Mode 255 = Jam Bypass
742-040 OCT Start Timing (Offset) 42 0~202
(1bit= 2.4462ms)
OCT (Offset) Start Timing Adjustment (P Speed)
742-041 OCT Start Timing (Offset) 42 0~202
(1bit= 1.31136ms)
OCT (Offset) Start Timing Adjustment (Double Speed)
742-046 Face Up Tray Condition 0 0~1 Face Up Tray Present 0 = No 1 = Yes
742-047 OCT Start Timing (Home) 17 0~112
(1bit= 2.4462ms)
OCT (Home) Start Timing Adjustment (P Speed)
Table 8 Chain 742
Chain-Link Name Default Range Description
