Xerox DocuColor 1632

6/02
6-22
DC1632/2240
Prelaunch Training/Review
General Procedures and Information
741--xxx Drive NVM List
742--xxx Paper Handling NVM List
Table 7 Chain 741
Chain-Link Name Default Range Description
741-054 NVM_PR_MOT_HIGH_PULSE (PR
(Drum) Motor Speed Fine Adjustment
(Standard)
23 0~40 Performs fine adjustment of Drum Speed at Standard Speed. Increases the Drum Speed by +1 (approx. 0.05%)
with respect to the initial value. Decreases the Drum Speed by -1 (approx. 0.05%).
741-055 NVM_PR_MOT_LOW_PULSE (PR
(Drum) Motor Speed Fine Adjustment
(Heavy Weight /Transparency)
23 0~40 Fine adjusts the Drum Speed at half speed. Increases the Drum Speed by +1 (approx. 0.05%) with respect to
the initial value. Decreases the Drum Speed by -1 (approx. 0.05%).
741-056 Belt Home Fail Too Long Counter 0 0~3 It is necessary to reset the No. of Occurrence of Belt Home Fail Too Long to 3.
741-057 NoPaperRun Mode SW 0 0~2 0 = Normal NoPaperRun 1 = MainMotor Stop 2 = Main/Dev. Motor Stop
741-068 NVM_PR_MOT_DOUBLE_PULSE (PR
(Drum) Motor Speed Fine Adjustment
(Double Speed)
22 0~40 Fine adjusts the Drum Speed at double speed. Increases the Drum Speed by +1 (approx. 0.05%) with respect
to the initial value. Decreases the Drum Speed by -1 (approx. 0.05%).
Table 8 Chain 742
Chain-Link Name Default Range Description
742-001 Invert Clutch CW Off Timing 82 0~163
(1bit= 2.4462ms)
Paper inversion position adjustment (P Speed) default=2300ms
742-002 Invert Clutch CW Off Timing (MF-1) 106 0~259
(1bit= 1.31136ms)
Paper inversion position adjustment (Double Speed)
742-006 RegiLoopLengthAjust (Tray Standard
Paper)
41 0~81
(1bit= 2.4462ms)
Regi Loop Length Adjustment (P Speed) for Standard Paper from Tray. Default=260ms
742-007 RegiLoopLengthAjust (Tray Standard
Paper) (MF)
41 0~81
(1bit= 1.31136ms)
Regi Loop Length Adjustment (Double Speed) for Standard Paper from Tray
742-009 RegiLoopLengthAjust (Tray 5 Standard
Paper)
41 0~81 Regi Loop Length Adjustment (P Speed) for Standard Paper from Tray 5 (1bit= 2.4462ms)
742-011 RegiLoopLengthAjust (Tray 5 Standard
Paper) (MF)
41 0~81
(1bit= 1.322ms)
Regi Loop Length Adjustment (Double Speed) for Standard Paper from MSI
742-013 RegiLoopLengthAjust (Tray 5 Heavy2
Paper)
41 0~81
(1bit= 4.8924ms)
Regi Loop Length Adjustment (Half Speed) for Heavy Weight Paper from MSI. Default=221ms
742-014 RegiLoopLengthAjust (DUP) (2sheets
of paper)
41 0~81
(1bit= 2.4462ms)
Regi Loop Length Adjustment (P Speed) from Dup (Feeding length Letter-LEF and Shorter) Default=157ms
742-015 RegiLoopLengthAjust (DUP) (MF) 76 0~152
(1bit= 1.31136ms)
Regi Loop Length Adjustment (Double Speed) from Dup
742-016 T/A Clutch On Timing (From Regi Start) 20 8~32
(1bit= 2.4462ms)
Synchronize adjustment to be same as Regi Clutch at Regi Start (-30~30ms) Default=0ms
742-017 Dup On Timing (From Regi Start) 20 0~40
(1bit= 2.4462ms)
Synchronize adjustment to be same as Regi Clutch at Regi Start (P Speed). Default=373ms
742-018 Full Stack Paper Sensing Condition 2 1~12 (1bit= 5sec) Full Stack Detection Condition (5~60sec).
742-019 Full Stack Paper Cancel Condition 1 1~30 (1bit= 1sec) Full Stack Cancel Condition (1~30sec)
742-020 Feed Start Timing (MSI) 41 0~82 (1bit=
2.4462ms)
Feed Start Timing Adjustment from Pitch (P Speed) (850~1050ms). Default=950ms
