6/02
6-31
DC1632/2240
General Procedures and Information
Prelaunch Training/Review
746-413 Output Remote for DTS twice-speed
Side2
50 0~100 (1bit= 1%) Displays the multiplication value by DTS output adjustment
746-423 Toner Band Width (in process direction) 3 0~22 (1bit= 1mm) For adjustment of Toner Band Width in process direction
746-424 Toner Band Width (in axial direction) 137 0~137
(1bit= 1mm)
For adjustment of Toner Band Width in axial direction
746-425 Toner Band Density 60 10~100
(1bit= 1%)
For adjustment of Toner Band Density
746-959 2nd CLN MINUS BIAS OUTPUT (for
Environment no.0, 1, 2, 3)
123 102~921
(1bit= -4.888V)
For 2ND BTR Cleaning Bias setup for each environment The resistance detection result of remote cannot be
reflected
746-960 2nd CLN MINUS BIAS OUTPUT (for
Environment no.4)
123 102~921
(1bit= -4.888V)
For 2ND BTR Cleaning Bias setup for each environment. The resistance detection result of remote cannot be
reflected
746-961 2nd CLN MINUS BIAS OUTPUT (for
Environment no.5, 6)
123 102~921
(1bit= -4.888V)
For 2ND BTR Cleaning Bias setup for each environment. The resistance detection result of remote cannot be
reflected
746-962 2nd CLN MINUS BIAS OUTPUT (for
Environment no.7, 8, 9)
123 102~921
(1bit= -4.888V)
For 2ND BTR Cleaning Bias setup for each environment. The resistance detection result of remote cannot be
reflected
746-963 Y offset distance 16 0~16 (1bit= 1ms) Distance of 0ms~39ms between Drum contact and 1ST BTR
746-964 M offset distance 16 0~16 (1bit= 1ms) Distance of 0ms~39ms between Drum contact and 1ST BTR
746-965 C offset distance 16 0~16 (1bit= 1ms) Distance of 0ms~39ms between Drum contact and 1ST BTR
746-966 K offset distance 16 0~16 (1bit= 1ms) Distance of 0ms~39ms between Drum contact and 1ST BTR
746-967 1st BTR Vmonitor Y 36 4~178
(1bit= 28.01V)
Displays the voltage at primary transfer resistance detection (100~5000V)
746-968 1st BTR Vmonitor M 36 4~178
(1bit= 28.01V)
Displays the voltage at primary transfer resistance detection (100~5000V)
746-969 1st BTR Vmonitor C 36 4~178
(1bit= 28.01V)
Displays the voltage at primary transfer resistance detection (100~5000V)
746-970 1st BTR Vmonitor K 36 4~178
(1bit= 28.01V)
Displays the voltage at primary transfer resistance detection (100~5000V)
746-971 Remote for Plain paper A ~G Normal
speed BW Side1
100 0~200 (1bit= 1%) For Secondary Transfer output adjustment of Plain paper A ~G 104mmsec side1 BW. Displays the multiplica-
tion value in secondary transfer resistance calculation result of 746-006.
746-972 Remote for Plain paper A ~G twice
speed BW Side1
100 0~200 (1bit= 1%) For Secondary Transfer output adjustment of Plain paper A ~G 194mmsec side1 BW. Displays the multiplica-
tion value in secondary transfer resistance calculation result of 746-006.
746-973 Remote for Plain paper A ~G Normal
speed BW Side2
100 0~200 (1bit= 1%) For Secondary Transfer output adjustment of Plain paper A ~G 104mmsec side2 BW. Displays the multiplica-
tion value in secondary transfer resistance calculation result of 746-006.
746-974 Remote for Plain paper A ~G twice
speed BW Side2
100 0~200 (1bit= 1%) For Secondary Transfer output adjustment of Plain paper A ~G 194mmsec side2 BW. Displays the multiplica-
tion value in secondary transfer resistance calculation result of 746-006.
746-975 Remote for Plain paper S Normal
speed BW Side1
100 0~200 (1bit= 1%) For Secondary Transfer output adjustment of Plain paper S 104mmsec side1 BW. Displays the multiplication
value in secondary transfer resistance calculation result of 746-006.
746-976 Remote for Plain paper S twice speed
BW Side1
100 0~200 (1bit= 1%) For Secondary Transfer output adjustment of Plain paper S 194mmsec side1 BW. Displays the multiplication
value in secondary transfer resistance calculation result of 746-006.
746-977 Remote for Plain paper S Normal
speed BW Side2
100 0~200 (1bit= 1%) For Secondary Transfer output adjustment of Plain paper S 104mmsec side2 BW. Displays the multiplication
value in secondary transfer resistance calculation result of 746-006.
746-978 Remote for Plain paper S twice speed
BW Side2
100 0~200 (1bit= 1%) For Secondary Transfer output adjustment of Plain paper S 194mmsec side2 BW. Displays the multiplication
value in secondary transfer resistance calculation result of 746-006.
Table 10 Chain 746
Chain-Link Name Default Range Description
