6/02
6-37
DC1632/2240
General Procedures and Information
Prelaunch Training/Review
753-011 P LUTCin [Color] [A] 102 0~255 [2P TRC] P LUTCin (fixed number) when the Delta LUT is calculated.
753-012 P LUTCin [Color] [B] 204 0~255 [2P TRC] P LUTCin (fixed number) when the Delta LUT is calculated.
753-013 P LUTCin [Color] [D] 255 0~255 [2P TRC] P LUTCin (fixed number) when the Delta LUT is calculated.
753-014 Patch Cin [Y] [CinA] 102 0~255 [2P TRC] = 2P Patch Cin (Value is changed by the gradation correction result). (Change factor from MF)
Changes name from [TRC Patch Cin in Job]
753-015 Patch Cin [M] [CinA] 102 0~255 [2P TRC] = 2P Patch Cin (Value is changed by the gradation correction result). (Change factor from MF)
Changes name from [TRC Patch Cin in Job]
753-016 Patch Cin [C] [CinA] 102 0~255 [2P TRC] = 2P Patch Cin (Value is changed by the gradation correction result). (Change factor from MF)
Changes name from [TRC Patch Cin in Job]
753-017 Patch Cin [K] [CinA] 77 0~255 [2P TRC] = 2P Patch Cin (Value is changed by the gradation correction result). (Change factor from MF)
Changes name from [TRC Patch Cin in Job]
753-018 Patch Cin [Y] [CinB] 204 0~255 [2P TRC] = 2P Patch Cin (Value is changed by the gradation correction result). (Change factor from MF)
Changes name from [TRC Patch Cin in Job]
753-019 Patch Cin [M] [CinB] 204 0~255 [2P TRC] = 2P Patch Cin (Value is changed by the gradation correction result). (Change factor from MF)
Changes name from [TRC Patch Cin in Job]
753-020 Patch Cin [C] [CinB] 204 0~255 [2P TRC] = 2P Patch Cin (Value is changed by the gradation correction result). (Change factor from MF)
Changes name from [TRC Patch Cin in Job]
753-021 Patch Cin [K] [CinB] 134 0~255 [2P TRC] = 2P Patch Cin (Value is changed by the gradation correction result). (Change factor from MF)
Changes name from [TRC Patch Cin in Job]
753-022 TRC Target RADC [Y] [A] 780 0~1023 [2P TRC] Target RADC for Gradation Correction
753-023 TRC Target RADC [Y] [B] 415 0~1023 [2P TRC] Target RADC for Gradation Correction
753-024 TRC Target RADC [M] [A] 740 0~1023 [2P TRC] Target RADC for Gradation Correction
753-025 TRC Target RADC [M] [B] 360 0~1023 [2P TRC] Target RADC for Gradation Correction
753-026 TRC Target RADC [C] [A] 725 0~1023 [2P TRC] Target RADC for Gradation Correction
753-027 TRC Target RADC [C] [B] 355 0~1023 [2P TRC] Target RADC for Gradation Correction
753-028 TRC Target RADC [K] [A] 730 0~1023 [2P TRC] Target RADC for Gradation Correction
753-029 TRC Target RADC [K] [B] 310 0~1023 [2P TRC] Target RADC for Gradation Correction
753-030 TRC Current RADC [Y] [A] 780 0~1023 [2P TRC] Current RADC for Gradation Correction
753-031 TRC Current RADC [Y] [B] 415 0~1023 [2P TRC] Current RADC for Gradation Correction
753-032 TRC Current RADC [M] [A] 740 0~1023 [2P TRC] Current RADC for Gradation Correction
753-033 TRC Current RADC [M] [B] 360 0~1023 [2P TRC] Current RADC for Gradation Correction
753-034 TRC Current RADC [C] [A] 725 0~1023 [2P TRC] Current RADC for Gradation Correction
753-035 TRC Current RADC [C] [B] 355 0~1023 [2P TRC] Current RADC for Gradation Correction
753-036 TRC Current RADC [K] [A] 730 0~1023 [2P TRC] Current RADC for Gradation Correction
753-037 TRC Current RADC [K] [B] 310 0~1023 [2P TRC] Current RADC for Gradation Correction
753-801 Legible Y 1024 0~2047 Legible Adjustment (Y)
753-802 Legible M 1024 0~2047 Legible Adjustment (M)
753-803 Legible C 1024 0~2047 Legible Adjustment (C)
753-804 Legible K 1024 0~2047 Legible Adjustment (K)
753-805 Pattern Y 0 0~19 InOut Pattern Setup (Y)
753-806 Pattern M 0 0~19 InOut Pattern Setup (M)
753-807 Pattern C 0 0~19 InOut Pattern Setup (C)
Table 13 Chain 753
Chain-Link Name Default Range Description
