6/02
6-41
DC1632/2240
General Procedures and Information
Prelaunch Training/Review
760-xxx Regicon NVM List
Table 15 Chain 760
Chain-Link Name Default Range Description
760-006 Block 3 0~4 Threshold of pattern valid no. of Blocks. Fail occurs if the value is not corrected below the Threshold.
760-007 Y-MAG 716 0~1432 Adjusts the Fast Scan direction image 100% magnification by switching the average frequency of each ROS
Video lock. (4 Colors/Correction Resolution Ability = 1/4 Pixel unit)
760-008 M-MAG 716 0~1432 Adjusts the Fast Scan direction image 100% magnification by switching the average frequency of each ROS
Video lock. (4 Colors/Correction Resolution Ability = 1/4 Pixel unit)
760-009 C-MAG 716 0~1432 Adjusts the Fast Scan direction image 100% magnification by switching the average frequency of each ROS
Video lock. (4 Colors/Correction Resolution Ability = 1/4 Pixel unit)
760-010 K-MAG 716 0~1432 Adjusts the Fast Scan direction image 100% magnification by switching the average frequency of each ROS
Video lock. (4 Colors/Correction Resolution Ability = 1/4 Pixel unit)
760-011 Y-BAL 421 0~842 Adjusts the Left Right Magnification with respect to Fast Scan direction image center by changing the slant of
ROS Video Lock Sweep. (4 Colors/Correction Resolution Ability = 1/8 Pixel unit)
760-012 M-BAL 421 0~842 Adjusts the Left Right Magnification with respect to Fast Scan direction image center by changing the slant of
ROS Video Lock Sweep. (4 Colors/Correction Resolution Ability = 1/8 Pixel unit)
760-013 C-BAL 421 0~842 Adjusts the Left Right Magnification with respect to Fast Scan direction image center by changing the slant of
ROS Video Lock Sweep. (4 Colors/Correction Resolution Ability = 1/8 Pixel unit)
760-014 K-BAL 421 0~842 Adjusts the Left Right Magnification with respect to Fast Scan direction image center by changing the slant of
ROS Video Lock Sweep. (4 Colors/Correction Resolution Ability = 1/8 Pixel unit)
760-015 Y-Skew misregistration 500 0~1000 100=1 rotation. 500 and above=CW direction, Below 500=CCW direction
760-016 M-Skew misregistration 500 0~1000 100=1 rotation. 500 and above=CW direction, Below 500=CCW direction
760-017 C-Skew misregistration 500 0~1000 100=1 rotation. 500 and above=CW direction, Below 500=CCW direction
760-018 K-Skew misregistration 500 0~1000 100=1 rotation. 500 and above=CW direction, Below 500=CCW direction
760-019 Y-XSO 236 0~472 Adjusts the Fast Scan direction write start position by the No. of Video Locks from SOS Signal. (4 Colors/Cor-
rection Resolution Ability = 1 Pixel unit)
760-020 M-XSO 236 0~472 Adjusts the Fast Scan direction write start position by the No. of Video Locks from SOS Signal. (4 Colors/Cor-
rection Resolution Ability = 1 Pixel unit)
760-021 C-XSO 236 0~472 Adjusts the Fast Scan direction write start position by the No. of Video Locks from SOS Signal. (4 Colors/Cor-
rection Resolution Ability = 1 Pixel unit)
760-022 K-XSO 236 0~472 Adjusts the Fast Scan direction write start position by the No. of Video Locks from SOS Signal. (4 Colors/Cor-
rection Resolution Ability = 1 Pixel unit)
760-023 Y-YSO 237 0~474 Adjusts the Slow Scan direction write start position by the No. of LS Signal Counts from the ROS/Image/Patch
Start Signal. (4 Colors/Correction Resolution Ability = 1 Pixel unit)
760-024 M-YSO 237 0~474 Adjusts the Slow Scan direction write start position by the No. of LS Signal Counts from the ROS/Image/Patch
Start Signal. (4 Colors/Correction Resolution Ability = 1 Pixel unit)
760-025 C-YSO 237 0~474 Adjusts the Slow Scan direction write start position by the No. of LS Signal Counts from the ROS/Image/Patch
Start Signal. (4 Colors/Correction Resolution Ability = 1 Pixel unit)
760-026 K-YSO 237 0~474 Adjusts the Slow Scan direction write start position by the No. of LS Signal Counts from the ROS/Image/Patch
Start Signal. (4 Colors/Correction Resolution Ability = 1 Pixel unit)
760-027 Regi Con/Circum. Length Correction
implement SW
3 0~3 For check during servicing etc. 0 = Does not perform Regi Control nor Circumference Length Correction 1 =
Performs Regi Control, does not perform Circumference Length Correction 2 = Does not perform Regi Control,
performs Circumference Length Correction 3 = Performs Regi Control and Circumference Length Correction
760-028 RC Start Temp 40 10~250 Threshold of (Normal) Regi Control Implementation Temperature difference. Value on the left is 10 times of the
Temperature. (0.1 Degree Celsius interval)
To Next Page
