Xerox DocuColor 1632 Service Manual

6/02
6-42
DC1632/2240
Prelaunch Training/Review
General Procedures and Information
760-029 OLRC implementation SW 1 0~1 0 = Does not perform OLRegi Control 1 = Performs OLRegi Control
760-030 Y-OLRC Start Temp 30 10~100 Threshold of Yellow Open Loop Regi Control Implementation Temperature difference. Value on the left is 10
times of the Temperature. (0.1 Degree Celsius interval)
760-031 M-OLRC Start Temp 30 10~100 Threshold of Magenta Open Loop Regi Control Implementation Temperature difference. Value on the left is 10
times of the Temperature. (0.1 Degree Celsius interval)
760-032 K-OLRC Start Temp 30 10~100 Threshold of Black Open Loop Regi Control Implementation Temperature difference. Value on the left is 10
times of the Temperature. (0.1 Degree Celsius interval)
760-035 Aok (for Diag Regi Con) 20 1~24 Threshold of No. of valid Blocks of fine adjustment pattern at Diag Regi Control (DC685). NG occurs if the value
is out corrected below the Threshold.
760-036 Aok (for normal Regi Con) 8 1~12 Threshold of No. of valid Blocks of fine adjustment pattern at Normal Regi Control. NG occurs if the value is out
corrected below the Threshold.
760-037 LEDset-IN-A 2 0~2 MOB LED ON/OFF and Light Quantity Step at IN side. 0 = Off 1 = Low 2 = High
760-038 LEDset-IN-B 2 0~2 MOB LED ON/OFF and Light Quantity Step at IN side.0 = Off 1 = Low 2 = High
760-043 LEDset-OUT-A 2 0~2 MOB LED ON/OFF and Light Quantity Step at OUT side. 0 = Off 1 = Low 2 = High
760-044 LEDset-OUT-B 2 0~2 MOB LED ON/OFF and Light Quantity Step at OUT side 0 = Off 1 = Low 2 = High
760-049 Y-XBI 0 0~3 Adjusts the Fast Scan direction write start position by Switching the Video Lock position phase from SOS Sig-
nal. (4 Colors/Correction Resolution Ability = 1 Pixel unit)
760-050 M-XBI 0 0~3 Adjusts the Fast Scan direction write start position by Switching the Video Lock position phase from SOS Sig-
nal. (4 Colors/Correction Resolution Ability = 1 Pixel unit)
760-051 C-XBI 0 0~3 Adjusts the Fast Scan direction write start position by Switching the Video Lock position phase from SOS Sig-
nal. (4 Colors/Correction Resolution Ability = 1 Pixel unit)
760-052 K-XBI 0 0~3 Adjusts the Fast Scan direction write start position by Switching the Video Lock position phase from SOS Sig-
nal. (4 Colors/Correction Resolution Ability = 1 Pixel unit)
760-053 Y-OLXSO 10 0~20 The normal Regi Control cycle, separately adjusts the Fast Scan direction write start position by the No. of
Video Locks from SOS signal in an Open Loop, from the temperature detection result. (4 Colors/Correction
Resolution Ability = 1 Pixel unit)
760-054 M-OLXSO 10 0~20 The normal Regi Control cycle, separately adjusts the Fast Scan direction write start position by the No. of
Video Locks from SOS signal in an Open Loop, from the temperature detection result. (4 Colors/Correction
Resolution Ability = 1 Pixel unit)
760-055 C-OLXSO 10 0~20 The normal Regi Control cycle separately adjusts the Fast Scan direction write start position by the No. of Video
Locks from SOS signal in an Open Loop, from the temperature detection result. (4 Colors/Correction Resolution
Ability = 1 Pixel unit)
760-056 K-OLXSO 10 0~20 The normal Regi Control cycle, separately adjusts the Fast Scan direction write start position by the No. of
Video Locks from SOS signal in an Open Loop, from the temperature detection result. (4 Colors/Correction
Resolution Ability = 1 Pixel unit)
760-057 Y-OLXBI 0 0~3 The normal Regi Control cycle, separately adjusts the Fast Scan direction write start position by replacing the
Video Locks phase from SOS signal in an Open Loop, from the temperature detection result. (4 Colors/Correc-
tion Resolution Ability = 1 Pixel unit)
760-058 M-OLXBI 0 0~3 The normal Regi Control cycle, separately adjusts the Fast Scan direction write start position by replacing the
Video Locks phase from SOS signal in an Open Loop, from the temperature detection result. (4 Colors/Correc-
tion Resolution Ability = 1 Pixel unit)
760-059 O-OLXBI 0 0~3 The normal Regi Control cycle, separately adjusts the Fast Scan direction write start position by replacing the
Video Locks phase from SOS signal in an Open Loop, from the temperature detection result. (4 Colors/Correc-
tion Resolution Ability = 1 Pixel unit)
Table 15 Chain 760
Chain-Link Name Default Range Description
