Xerox DocuColor 1632 Service Manual

6/02
6-43
DC1632/2240
General Procedures and Information
Prelaunch Training/Review
760-060 K-OLXBI 0 0~3 The normal Regi Control cycle, separately adjusts the Fast Scan direction write start position by replacing the
Video Locks phase from SOS signal in an Open Loop, from the temperature detection result. (4 Colors/Correc-
tion Resolution Ability = 1 Pixel unit)
760-061 Y-OLYSO 4 0~20 The normal Regi Control cycle, separately adjusts the Slow Scan direction write start position by the LS signal
No. of Counts from the ROS Image/Patch start signal in an Open Loop from the Temperature detection result.
(4 Colors/Correction Resolution Ability = 1 Pixel unit)
760-062 M-OLYSO 10 0~20 The normal Regi Control cycle, separately adjusts the Slow Scan direction write start position by the LS signal
No. of Counts from the ROS Image/Patch start signal in an Open Loop from the Temperature detection result.
(4 Colors/Correction Resolution Ability = 1 Pixel unit)
760-063 C-OLYSO 10 0~20 The normal Regi Control cycle, separately adjusts the Slow Scan direction write start position by the LS signal
No. of Counts from the ROS Image/Patch start signal in an Open Loop from the Temperature detection result.
(4 Colors/Correction Resolution Ability = 1 Pixel unit)
760-064 K-OLYSO 10 0~20 The normal Regi Control cycle, separately adjusts the Slow Scan direction write start position by the LS signal
No. of Counts from the ROS Image/Patch start signal in an Open Loop from the Temperature detection result.
(4 Colors/Correction Resolution Ability = 1 Pixel unit)
760-065 Y-OLMAG 100 0~200 The normal Regi Control separately adjusts the Fast Scan direction image 100% magnification by switching the
average frequency of each ROS Video Lock in an Open Loop from the Temperature detection result. (4 Colors/
Correction Resolution Ability = 1/4 Pixel unit)
760-066 M-OLMAG 100 0~200 The normal Regi Control separately adjusts the Fast Scan direction image 100% magnification by switching the
average frequency of each ROS Video Lock in an Open Loop from the Temperature detection result. (4 Colors/
Correction Resolution Ability = 1/4 Pixel unit)
760-067 C-OLMAG 100 0~200 The normal Regi Control separately adjusts the Fast Scan direction image 100% magnification by switching the
average frequency of each ROS Video Lock in an Open Loop from the Temperature detection result. (4 Colors/
Correction Resolution Ability = 1/4 Pixel unit)
760-068 K-OLMAG 100 0~200 The normal Regi Control separately adjusts the Fast Scan direction image 100% magnification by switching the
average frequency of each ROS Video Lock in an Open Loop from the Temperature detection result. (4 Colors/
Correction Resolution Ability = 1/4 Pixel unit)
760-070 Y-LD light volume at last RegiCon 0 0~1023 LD Light Quantity when Regi Control is performed.
760-071 M-LD light volume at last RegiCon 0 0~1023 LD Light Quantity when Regi Control is performed.
760-072 C-LD light volume at last RegiCon 0 0~1023 LD Light Quantity when Regi Control is performed.
760-073 K-LD light volume at last RegiCon 0 0~1023 LD Light Quantity when Regi Control is performed.
760-074 Y-XSO after LD light volume change 236 0~472 XSO value after correction based on the LD Light Quantity variation
760-075 M-XSO after LD light volume change 236 0~472 XSO value after correction based on the LD Light Quantity variation
760-076 C-XSO after LD light volume change 236 0~472 XSO value after correction based on the LD Light Quantity variation
760-077 K-XSO after LD light volume change 236 0~472 XSO value after correction based on the LD Light Quantity variation
760-078 Y-XBI after LD light volume change 0 0~3 XBI value after correction based on the LD Light Quantity variation
760-079 M-XBI after LD light volume change 0 0~3 XBI value after correction based on the LD Light Quantity variation
760-080 C-XBI after LD light volume change 0 0~3 XBI value after correction based on the LD Light Quantity variation
760-081 K-XBI after LD light volume change 0 0~3 XBI value after correction based on the LD Light Quantity variation
Table 15 Chain 760
Chain-Link Name Default Range Description
