Xerox DocuColor 1632 Service Manual

6/02
6-44
DC1632/2240
Prelaunch Training/Review
General Procedures and Information
762-xxx Developer NVM List
Table 16 Chain 762
Chain-Link Name Default Range Description
762-002 #YMC Normal VM1 value 351 0~1023
(1bit= -0.684V)
Vm1 Developer DC energized voltage at YMC Color/Normal speed (104mm/s)
762-008 #YM_DB AC Normal Vp-p value 600 0~1023
(1bit= 1.491Vpp)
AC peak to peak energized voltage at YM Color/Normal speed.
762-012 #K_DB DC Normal Vm1 value 351 0~1023
(1bit= -0.684V)
Vm1 Developer DC energized voltage at K Color/Normal speed (104mm/s)
762-013 #CK_DB AC Normal Vp-p value 600 0~1023
(1bit= 1.491Vpp)
AC peak to peak energized voltage at CK Color/Normal speed.
762-018 #YMC_DB DC Half-speed Vm1 value 351 0~1023
(1bit= -0.684V)
Vm1 Developer DC energized voltage at YMC Color/Half speed (52mm/s)
762-024 #YM_DB AC Half-speed Vp-p value 600 0~1023
(1bit= 1.491Vpp)
AC peak to peak energized voltage at YM Color/Half speed.
762-028 #K_DB DC Half-speed Vm1 value 351 0~1023
(1bit= -0.684V)
Vm1 Developer DC energized voltage at K Color/Half speed (52mm/s)
762-029 #CK_DB AC Half-speed Vp-p value 600 0~1023
(1bit= 1.491Vpp)
AC peak to peak energized voltage at CK Color/Half speed.
762-043 Pixel/Drum rotation threshold for Deve-
Band
20 0~65535 A standard value (Cumulative No. of Pixels/Drum Rotations) for creation DeveBand.
762-044 Cumulative ICDC_Band_Value_Y 0 0~409600 Y Color Cumulative Pixels
762-045 Cumulative ICDC_Band_Value_M 0 0~409600 M Color Cumulative Pixels
762-046 Cumulative ICDC_Band_Value_C 0 0~409600 C Color Cumulative Pixels
762-047 Cumulative ICDC_Band_Value_K 0 0~409600 K Color Cumulative Pixels
762-053 #YM_DB AC Normal Frequency 60 0~127 AC Energized Voltage Frequency at YM Color Normal Speed
762-054 #YM_DB AC Normal Output Phase
value
65 0~127 AC Energized Voltage Phase Value at YM Color Normal Speed
762-059 #CK_DB AC Normal Frequency 60 0~127 AC Energized Voltage Frequency at CK Color Normal Speed
762-060 #CK_DB AC Normal Output Phase
value
65 0~127 AC Energized Voltage Phase Value at CK Color Normal Speed
762-064 #YM_DB AC Half-speed Frequency 60 0~127 AC Energized Voltage Frequency at YM Color Half Speed
762-065 YM_DB AC Half-speed Output Phase
value
65 0~127 AC Energized Voltage Phase Value at YM Color Half Speed
762-070 #CK_DB AC Half-speed Frequency 60 0~127 AC Energized Voltage Frequency at CK Color Half Speed
762-071 #CK_DB AC Half-speed Output Phase
value
65 0~127 AC Energized Voltage Phase Value at CK Color Half Speed
762-081 #Y_DB DC VB1 ON Normal Timing 110 0~255
(1bit= 2.4462ms)
Rising timing from Vm1 to VB1 at Y Color Normal Speed.
762-082 #M_DB DC VB1 ON Normal Timing 110 0~255
(1bit= 2.4462ms)
Rising timing from Vm1 to VB1 at M Color Normal Speed.
762-083 #C_DB DC VB1 ON Normal Timing 110 0~255 Rising timing from Vm1 to VB1 at C Color Normal Speed. (1bit= 2.4462ms)
762-084 #K_DB DC VB1 ON Normal Timing 102 0~255 Rising timing from Vm1 to VB1 at K Color Normal Speed. (1bit= 2.4462ms)
762-089 #Y_DB DC VB OFF Normal Timing 90 0~255 Falling timing from VB to VB2 at Y Color Normal Speed. (1bit= 2.4462ms)
