Xerox DocuColor 1632 Service Manual

6/02
6-45
DC1632/2240
General Procedures and Information
Prelaunch Training/Review
762-090 #M_DB DC VB OFF Normal Timing 90 0~255 Falling timing from VB to VB2 at M Color Normal Speed. (1bit= 2.4462ms)
762-091 #C_DB DC VB OFF Normal Timing 90 0~255 Falling timing from VB to VB2 at C Color Normal Speed. (1bit= 2.4462ms)
762-092 #K_DB DC VB OFF Normal Timing 82 0~255 Falling timing from VB to VB2 at K Color Normal Speed. (1bit= 2.4462ms)
762-093 #YM_DB AC ON Normal Timing 110 0~255 AC Voltage Energized timing at YM Color Normal Speed. (1bit= 2.4462ms)
762-094 #CK_DB AC ON Normal Timing 110 0~255 AC Voltage Energized timing at CK Color Normal Speed. (1bit= 2.4462ms)
762-095 #YM_DB AC OFF Normal Timing 118 0~255 AC Voltage off timing at YM Color Normal Speed. (1bit= 2.4462ms)
762-096 #CK_DB AC OFF Normal Timing 118 0~255 AC Voltage Off timing at CK Color Normal Speed.
762-105 #Y_DB DC VB1 ON Half-speed Timing 104 0~255 (1bit=
4.8924ms)
Rising timing from Vm1 to VB1 at Y Color Half Speed.
762-106 #M_DB DC VB1 ON Half-speed Timing 104 0~255 (1bit=
4.8924ms)
Rising timing from Vm1 to VB1 at M Color Half Speed.
762-107 #C_DB DC VB1 ON Half-speed Timing 104 0~255 (1bit=
4.8924ms)
Rising timing from Vm1 to VB1 at C Color Half Speed.
762-108 #K_DB DC VB1 ON Half-speed Timing 94 0~255 (1bit=
4.8924ms)
Rising timing from Vm1 to VB1 at K Color Half Speed.
762-113 #Y_DB DC VB OFF Half-speed Timing 92 0~255 (1bit=
4.8924ms)
Falling timing from VB to VB2 at Y Color Half Speed.
762-114 #M_DB DC VB OFF Half-speed Timing 92 0~255 (1bit=
4.8924ms)
Falling timing from VB to VB2 at M Color Half Speed.
762-115 #C_DB DC VB OFF Half-speed Timing 92 0~255 (1bit=
4.8924ms)
Falling timing from VB to VB2 at C Color Half Speed.
762-116 #K_DB DC VB OFF Half-speed Timing 88 0~255 (1bit=
4.8924ms)
Falling timing from VB to VB2 at K Color Half Speed.
762-117 #YM_ DB AC ON Half-speed Timing 110 0~255 (1bit=
4.8924ms)
AC Voltage Energized timing at YM Color Half Speed.
762-118 #CK_ DB AC ON Half-speed Timing 110 0~255 (1bit=
4.8924ms)
AC Voltage Energized timing at CK Color Half Speed.
762-119 #YM_ DB AC OFF Half-speed Timing 108 0~255 (1bit=
4.8924ms)
AC Voltage off timing at YM Color Half Speed.
762-120 #CK_ DB AC OFF Half-speed Timing 108 0~255 (1bit=
4.8924ms)
AC Voltage off timing at CK Color Half Speed.
762-121 #YMC_Deve MOT ON Normal Timing 184 0~255 Color Developer during motor rising timing at Normal Speed. (1bit= 2.4462ms)
762-122 #YMC_Deve MOT OFF Normal Timing 303 0~1023 Color Developer during motor falling timing at Normal Speed. (1bit= 2.4462ms)
762-123 #YMC_Deve MOT ON Half-speed Tim-
ing
184 0~255 (1bit=
4.8924ms)
Color Developer during motor rising timing at Half Speed.
762-124 #YMC_Deve MOT OFF Half-speed
Timing
303 0~1023 (1bit=
4.8924ms)
Color Developer during motor falling timing at Half Speed.
762-134 #K_Deve C/L ON Normal Timing 164 0~255 K Color Developer during clutch rising timing at Normal Speed. (1bit= 2.4462ms)
762-135 #K_Deve C/L OFF Normal Timing 531 0~1023 K Color Developer during clutch falling timing at Normal Speed. (1bit= 2.4462ms)
762-136 #K_Deve C/L ON Half-speed Timing 164 0~255 (1bit=
4.8924ms)
K Color Developer during clutch rising timing at Half Speed.
762-137 #K_Deve C/L OFF Half-speed Timing 531 0~1023 (1bit=
4.8924ms)
K Color Developer during clutch falling timing at Half Speed.
Table 16 Chain 762
Chain-Link Name Default Range Description
