DC1632/2240
Prelaunch Training/Review
General Procedures and Information
762-173 #Y_DB DC VB ON Normal Timing 370 0~1023 Rising timing from VB3 to VB at Y Color Normal Speed. (1bit= 2.4462ms)
762-174 #M_DB DC VB ON Normal Timing 370 0~1023 Rising timing from VB3 to VB at M Color Normal Speed. (1bit= 2.4462ms)
762-175 #C_DB DC VB ON Normal Timing 370 0~1023 Rising timing from VB3 to VB at C Color Normal Speed. (1bit= 2.4462ms)
762-176 #K_DB DC VB ON Normal Timing 370 0~1023 Rising timing from VB3 to VB at K Color Normal Speed. (1bit= 2.4462ms)
762-177 #Y_DB DC VB ON Half-speed Timing 370 0~1023 (1bit=
4.8924ms)
Rising timing from VB3 to VB at Y Color Half Speed.
762-178 #M_DB DC VB ON Half-speed Timing 370 0~1023 (1bit=
4.8924ms)
Rising timing from VB3 to VB at M Color Half Speed.
762-179 #C_DB DC VB ON Half-speed Timing 370 0~1023 (1bit=
4.8924ms)
Rising timing from VB3 to VB at C Color Half Speed.
762-180 #K_DB DC VB ON Half-speed Timing 370 0~1023 (1bit=
4.8924ms)
Rising timing from VB3 to VB at K Color Half Speed.
762-185 #YMC_DB DC Normal VB3 Value 877 0~1023 (1bit= -
0.684V)
VB3 Developer DC Energized Voltage value of YMC Color/Normal Speed.
762-186 #K_DB DC Normal VB3 Value 877 0~1023 (1bit= -
0.684V)
VB3 Developer DC Energized Voltage value of K Color/Normal Speed.
762-187 #YMC_DB DC Half-speed VB3 Value 877 0~1023 (1bit= -
0.684V)
VB3 Developer DC Energized Voltage value of YMC Color/Half Speed.
762-188 #K_DB DC Half-speed VB3 Value 877 0~1023 (1bit= -
0.684V)
VB3 Developer DC Energized Voltage value of K Color/Half Speed.
762-190 #4DB DC Hi-speed VM1 Value 351 0~1023 (1bit= -
0.684V)
Vm1 Developer DC Energized Voltage value at K Color/High Speed.
762-194 #K_DB DC Hi-speed VM3 Value 877 0~1023 (1bit= -
0.684V)
VB3 Developer DC Energized Voltage value at K Color/High Speed.
762-195 #K_DB DC Vm0 ON Hi-speed Timing 107 0~255 (1bit=
1.3114ms)
Rising timing from 0v to Vm0 at K Color/High Speed.
762-196 #K_DB DC Vm1 OFF Hi-speed Timing 99 0~255 (1bit=
1.3114ms)
Falling timing from Vm1 to Vm0 at K Color/High Speed.
762-197 #K_DB DC VB1 ON Hi-speed Timing 130 0~255 (1bit=
1.3114ms)
Rising timing from Vm1 to VB1 at K Color/High Speed.
762-202 #K_DB DC VB OFF Hi-speed Timing 91 0~255 (1bit=
1.3114ms)
Falling timing from VB to VB2 at K Color/High Speed.
762-203 #CK_DB AC ON Hi-speed Timing 137 0~255 (1bit=
1.3114ms)
AC Voltage Energized timing at CK Color High Speed.
762-204 #CK_DB AC OFF Hi-speed Timing 137 0~255 (1bit=
1.3114ms)
AC Voltage off timing at CK Color High Speed.
762-210 #K_DB DC VB ON Hi-speed Timing 370 0~1023 (1bit=
1.3114ms)
Rising timing from VB3 to VB at K Color/High Speed.
762-211 #1, 2DB AC Target Value at 1200dpi 600 0~1023 (1bit=
1.491V)
AC peak to peak energized voltage at YM Color 1200dpi/Normal Speed Setup
762-213 #3, 4DB AC Target Value at 1200dpi 600 0~1023 (1bit=
1.491V)
AC peak to peak energized voltage at CK Color 1200dpi/Normal Speed Setup
762-215 #1, 2DB AC Target Value at 1200dpi/
Half-speed
600 0~1023 (1bit=
1.491V)
AC peak to peak energized voltage at YM Color 1200dpi/Half Speed Setup
Table 16 Chain 762
