Xerox DocuColor 1632 Service Manual

6/02
6-47
DC1632/2240
General Procedures and Information
Prelaunch Training/Review
762-217 #3, 4DB AC Target Value at 1200dpi/
Half-speed
600 0~1023 (1bit=
1.491V)
AC peak to peak energized voltage at CK Color 1200dpi/Half Speed Setup
762-219 toner_band_width_YMC 10 0~30 Xero/Deve band width Setup value at YMC Color
762-220 toner_band_width_K 10 0~30 Xero/Deve band width Setup value at K Color
762-221 toner_band_density_Half-speed_YMC 153 0~255 (1bit=
0.3922%)
Half Speed Xero/Deve band density setup value at YMC Color
762-222 toner_band_density_Half-speed_K 153 0~255 (1bit=
0.3922%)
Half Speed Xero/Deve band density setup value at K Color
762-223 toner_band_density_Normal_YMC 153 0~255 (1bit=
0.3922%)
Normal Speed Xero/Deve band density setup value at YMC Color
762-224 toner_band_density_Normal_K 153 0~255 (1bit=
0.3922%)
Normal Speed Xero/Deve band density setup value at K Color
762-225 toner_band_density_Hi-speed_YMC 51 0~255 (1bit=
0.3922%)
High Speed Xero/Deve band density setup value at YMC Color
762-226 toner_band_density_Hi-speed_K 153 0~255 (1bit=
0.3922%)
High Speed Xero/Deve band density setup value at K Color
762-228 #YM_DB AC Hi-speed Vp-p Value 600 0~1023 (1bit=
1.491Vpp)
AC peak to peak energized voltage at YM Color High Speed.
762-229 #CK_DB AC Hi-speed Vp-p Value 600 0~1023 (1bit=
1.491Vpp)
AC peak to peak energized voltage at CK Color High Speed.
762-231 #YM_DB AC Hi-speed Frequency 60 0~127 AC energized voltage frequency at YM Color High Speed.
762-232 #YM_DB AC Hi-speed Output Phase
Value
65 0~127 AC energized voltage phase value at YM Color High Speed.
762-233 #CK_DB AC Hi-speed Frequency 60 0~127 AC energized voltage frequency at CM Color High Speed.
762-234 #CK_DB AC Hi-speed Output Phase
Value
65 0~127 AC energized voltage phase value at CK Color High Speed.
762-236 #Y_DB DC Hi-speed Vm1 Value 351 0~1023 (1bit= -
0.684V)
Vm1 Developer DC Energized Voltage value at Y Color High Speed.
762-237 #M_DB DC Hi-speed Vm1 Value 351 0~1023 (1bit= -
0.684V)
Vm1 Developer DC Energized Voltage value at M Color High Speed.
762-238 #C_DB DC Hi-speed Vm1 Value 351 0~1023 (1bit= -
0.684V)
Vm1 Developer DC Energized Voltage value at C Color High Speed.
762-239 #Y_DB DC Hi-speed VB3 Value 877 0~1023 (1bit= -
0.684V)
VB3 Developer DC Energized Voltage value at Y Color High Speed.
762-240 M_DB DC Hi-speed VB3 Value 877 0~1023 (1bit= -
0.684V)
VB3 Developer DC Energized Voltage value at M Color High Speed.
762-241 #C_DB DC Hi-speed VB3 Value 877 0~1023 (1bit= -
0.684V)
VB3 Developer DC Energized Voltage value at C Color High Speed.
762-242 #Y_DB DC Vm0 ON Hi-speed Timing 366 0~2000 (1bit=
1.3114ms)
Rising timing from 0v to Vm0 at Y Color High Speed.
762-243 #M_DB DC Vm0 ON Hi-speed Timing 366 0~2000 (1bit=
1.3114ms)
Rising timing from 0v to Vm0 at M Color High Speed.
762-244 #C_DB DC Vm0 ON Hi-speed Timing 366 0~2000 (1bit=
1.3114ms)
Rising timing from 0v to Vm0 at C Color High Speed.
Table 16 Chain 762
