Xerox DocuColor 1632 Service Manual

6/02
6-48
DC1632/2240
Prelaunch Training/Review
General Procedures and Information
764-xxx Output (Finisher) NVM List
762-245 #Y_DB DC Vm1 OFF Hi-speed Timing 366 0~2000 (1bit=
1.3114ms)
Falling timing from Vm1 to Vm0 at Y Color High Speed.
762-246 #M_DB DC Vm1 OFF Hi-speed Timing 366 0~2000 (1bit=
1.3114ms)
Falling timing from Vm1 to Vm0 at M Color High Speed.
762-247 #C_DB DC Vm1 OFF Hi-speed Timing 366 0~2000 (1bit=
1.3114ms)
Falling timing from Vm1 to Vm0 at C Color High Speed.
762-248 #Y_DB DC VB1 ON Hi-speed Timing 366 0~2000 (1bit=
1.3114ms)
Rising timing from Vm1 to VB1 at Y Color High Speed.
762-249 #M_DB DC VB1 ON Hi-speed Timing 366 0~2000 (1bit=
1.3114ms)
Rising timing from Vm1 to VB1 at M Color High Speed.
762-250 #C_DB DC VB1 ON Hi-speed Timing 366 0~2000 (1bit=
1.3114ms)
Rising timing from Vm1 to VB1 at C Color High Speed.
762-251 #Y_DB DC VB OFF Hi-speed Timing 366 0~2000 (1bit=
1.3114ms)
Falling timing from VB to VB2 at Y Color High Speed.
762-252 #M_DB DC VB OFF Hi-speed Timing 366 0~2000 (1bit=
1.3114ms)
Falling timing from VB to VB2 at M Color High Speed.
762-253 #C_DB DC VB OFF Hi-speed Timing 366 0~2000 (1bit=
1.3114ms)
Falling timing from VB to VB2 at C Color High Speed.
762-254 #YM_DB AC ON Hi-speed Timing 366 0~2000 (1bit=
1.3114ms)
AC Voltage Energized timing at YM Color High Speed.
762-255 #YM_DB AC OFF Hi-speed Timing 366 0~2000 (1bit=
1.3114ms)
AC Voltage off timing at YM Color High Speed.
762-256 #Y_DB DC VB ON Hi-speed Timing 1382 0~2000 (1bit=
1.3114ms)
Rising timing from VB3 to VB at Y Color High Speed.
762-257 #M_DB DC VB ON Hi-speed Timing 1382 0~2000 (1bit=
1.3114ms)
Rising timing from VB3 to VB at M Color High Speed.
762-258 #C_DB DC VB ON Hi-speed Timing 1382 0~2000 (1bit=
1.3114ms)
Rising timing from VB3 to VB at C Color High Speed.
762-259 FPOT DB Vm0 ON Normal Timing 110 0~255 (1bit=
2.4462ms)
Rising timing from 0v to Vm0 at K Color FPOT.
762-260 FPOT DB Vm0 ON Hi-speed Timing 110 0~255 (1bit=
1.3114ms)
Rising timing from 0v to Vm0 at K Color FPOT.
762-261 FPOT DB AC ON Normal Timing 110 0~255 AC Voltage Energized timing at FPOT Normal Speed. (1bit= 2.4462ms)
762-262 FPOT DB AC ON Hi-speed Timing 110 0~255 (1bit=
1.3114ms)
AC Voltage Energized timing at FPOT High Speed.
Table 16 Chain 762
Chain-Link Name Default Range Description
Table 17 Chain 764
Chain-Link Name Default Range Description
764-001 Mix Stack 0 0~1 0 = Disable 1 = Enable
764-002 Set Count 50 10~100 Maximum No. of sets allowed
764-003 Unstaple Compile Sheet Count (Small
Size)
50 10~100 No. of Small Size paper compiled.
