6/02
6-49
DC1632/2240
General Procedures and Information
Prelaunch Training/Review
770-xxx ESS IO Port/Protocol Setting NVM List
764-004 Maximum Compile Sheet Count 50 10~100 No. of paper compiled.
764-005 Sheet Width of Last Ejected Sheet 65535 0~65535 Width of last ejected sheet on the Stacker. Rewrites in Sleep Mode
764-006 Sheet Length of Last Ejected Sheet 65535 0~65535 Length of last ejected sheet on the Stacker. Rewrites in Sleep Mode
764-007 Sheet Width of Maximum Size Sheet 65535 0~65535 Maximum paper size (Width) output to the Stacker. Rewrites in Sleep Mode
764-008 Sheet Length of Maximum Size Sheet 65535 0~65535 Maximum paper size (Length) output to the Stacker. Rewrites in Sleep Mode
764-009 Number Of Ejected Staple Set 0 0~255 No. of Stapled Sets output. Rewrites in Sleep Mode
764-010 Mix Sensor Level Indicate 0 0~1 MixSensor ON/OFF. Rewrites in Sleep Mode
764-011 Staple Mode of Last Set 255 0~255 Staple Mode of last set. Rewrites in Sleep Mode
764-012 Sleep Mode Recovery Indicate 0 0~1 Indication of entry into the Sleep Mode at IOT Recovery. Rewrites in Sleep Mode
764-013 Unstaple Compile Sheet Count (Large
Size)
25 10~100 No. of Large Size paper compiled.
Table 17 Chain 764
Chain-Link Name Default Range Description
Table 18 Chain 770
Chain-Link Name Default Range Description
770-001 Parallel Port Enable Enable 0~1 0 = Stop 1 = Start Up
770-002 Parallel Print ModeType Auto 1~23 1 = Auto, 14 = Dump, 15 = ART, 16 = PLW, 3 = HPGL2, 8 = ESCP, 5 = PostScript, 10 = TIFF (AP version 1 =
Auto, 2 = PCL6, 5 = PostScript
770-003 Parallel PJL Switch ON FALSE~TRUE 0 = OFF 1 = ON
770-004 Parallel Adobe Protocol Standard 0~2 0 = Standard 1 = Binary 2 = TBCP
770-005 Parallel Auto Feed Time 6
(30sec)
1~255 1-255 (5-1275 sec)
770-006 Parallel Input Prime ON 0~1 0 = OFF 1 = ON
770-007 Parallel COMM Mode ON 0~1 0 = ON 1 = OFF
770-009 TBD 0 0~1 0 = IEEE P1284 1 = Centronics
770-010 Ethernet Transfer Rate Auto - 0x7F = Auto, 2 = 100BASE-TX, 1 = 10BASE-T
770-030 NetWare Frame Type Auto - 255 = Auto 2 = Ethernet II 4 = Ethernet SNAP 3 = Ethernet 802.2 1 = Ethernet 802.3 6 = Token SNAP 5 =
Token 802.5
770-040 EtherTalk Port Enable Disable 0~1 0 = Disable 1 = Enable
770-041 EtherTalk Print Type Post-
Script
-PostScript
770-042 EtherTalk JCL Enable is EtherTalk PJL
Enable for AP
ON FALSE~TRUE 0 = OFF 1 = ON
770-050 Netware Port Enable Stop - 0 = Stop 1 = Start Up
770-051 Netware Print Mode Type Auto - 1 = Auto, 16 = ART, 17 = PLW, 3 = HPGL2, 8 = ESCP, 5 = PostScript, 10 = TIFF, 23 = Dump (AP Version 1 =
Auto, 2 = PCL6, 5 = PostScript)
770-052 Netware JCL Enable is Netware PJL
Enable for AP
ON FALSE~TRUE 0 = Cannot be used 1 = Can be used
770-053 NetWare TBCP Valid None FALSE~TRUE 0 = None 1 = TBCP
770-054 NetWare Trans. Protocol IPX/SPX - 1 = IPX/SPX, 2 = TCP/IP, 3 = both
770-060 Lpd Port Enable Start Up - 0 = Stop 1 = Start Up
To Next Page
