Xerox DocuColor 1632 Service Manual

6/02
6-55
DC1632/2240
General Procedures and Information
Prelaunch Training/Review
790-131 Fixed Size 1 of Copy Document Size
Input
13 1~50 1 = Postcard, 2 = A6SEF, 3 = A6LEF, 4 = B6SEF, 5 = B6LEF, 6 = A5SEF, 7 = A5LEF, 8 = B5SEF, 9 = B5LEF, 10
= A4SEF, 11 = A4LEF, 12 = B4SEF, 13 = A3SEF, 14 = Postcard (4x6), 15 = 5.5x8.5SEF, 16 = 5.5x8.5LEF, 17 =
8.5x11SEF, 18 = 8.5x11LEF
790-132 Fixed Size 2 of Copy Document Size
Input
10 1~50 1 = Postcard, 2 = A6SEF, 3 = A6LEF, 4 = B6SEF, 5 = B6LEF, 6 = A5SEF, 7 = A5LEF, 8 = B5SEF, 9 = B5LEF, 10
= A4SEF, 11 = A4LEF, 12 = B4SEF, 13 = A3SEF, 14 = Postcard (4x6), 15 = 5.5x8.5SEF, 16 = 5.5x8.5LEF, 17 =
8.5x11SEF, 18 = 8.5x11LEF
790-133 Fixed Size 3 of Copy Document Size
Input
11 1~50 1 = Postcard, 2 = A6SEF, 3 = A6LEF, 4 = B6SEF, 5 = B6LEF, 6 = A5SEF, 7 = A5LEF, 8 = B5SEF, 9 = B5LEF, 10
= A4SEF, 11 = A4LEF, 12 = B4SEF, 13 = A3SEF, 14 = Postcard (4x6), 15 = 5.5x8.5SEF, 16 = 5.5x8.5LEF, 17 =
8.5x11SEF, 18 = 8.5x11LEF
790-134 Fixed Size 4 of Copy Document Size
Input
6 1~50 1 = Postcard, 2 = A6SEF, 3 = A6LEF, 4 = B6SEF, 5 = B6LEF, 6 = A5SEF, 7 = A5LEF, 8 = B5SEF, 9 = B5LEF, 10
= A4SEF, 11 = A4LEF, 12 = B4SEF, 13 = A3SEF, 14 = Postcard (4x6), 15 = 5.5x8.5SEF, 16 = 5.5x8.5LEF, 17 =
8.5x11SEF, 18 = 8.5x11LEF
790-135 Fixed Size 5 of Copy Document Size
Input
7 1~50 1 = Postcard, 2 = A6SEF, 3 = A6LEF, 4 = B6SEF, 5 = B6LEF, 6 = A5SEF, 7 = A5LEF, 8 = B5SEF, 9 = B5LEF, 10
= A4SEF, 11 = A4LEF, 12 = B4SEF, 13 = A3SEF, 14 = Postcard (4x6), 15 = 5.5x8.5SEF, 16 = 5.5x8.5LEF, 17 =
8.5x11SEF, 18 = 8.5x11LEF
790-136 Fixed Size 6 of Copy Document Size
Input
12 1~50 1 = Postcard, 2 = A6SEF, 3 = A6LEF, 4 = B6SEF, 5 = B6LEF, 6 = A5SEF, 7 = A5LEF, 8 = B5SEF, 9 = B5LEF, 10
= A4SEF, 11 = A4LEF, 12 = B4SEF, 13 = A3SEF, 14 = Postcard (4x6), 15 = 5.5x8.5SEF, 16 = 5.5x8.5LEF, 17 =
8.5x11SEF, 18 = 8.5x11LEF
790-137 Fixed Size 7 of Copy Document Size
Input
8 1~50 1 = Postcard, 2 = A6SEF, 3 = A6LEF, 4 = B6SEF, 5 = B6LEF, 6 = A5SEF, 7 = A5LEF, 8 = B5SEF, 9 = B5LEF, 10
= A4SEF, 11 = A4LEF, 12 = B4SEF, 13 = A3SEF, 14 = Postcard (4x6), 15 = 5.5x8.5SEF, 16 = 5.5x8.5LEF, 17 =
8.5x11SEF, 18 = 8.5x11LEF
790-138 Fixed Size 8 of Copy Document Size
Input
9 1~50 1 = Postcard, 2 = A6SEF, 3 = A6LEF, 4 = B6SEF, 5 = B6LEF, 6 = A5SEF, 7 = A5LEF, 8 = B5SEF, 9 = B5LEF, 10
= A4SEF, 11 = A4LEF, 12 = B4SEF, 13 = A3SEF, 14 = Postcard (4x6), 15 = 5.5x8.5SEF, 16 = 5.5x8.5LEF, 17 =
8.5x11SEF, 18 = 8.5x11LEF
790-139 Fixed Size 9 of Copy Document Size
Input
11x17SE
F
1~50 1 = Postcard, 2 = A6SEF, 3 = A6LEF, 4 = B6SEF, 5 = B6LEF, 6 = A5SEF, 7 = A5LEF, 8 = B5SEF, 9 = B5LEF, 10
= A4SEF, 11 = A4LEF, 12 = B4SEF, 13 = A3SEF, 14 = Postcard (4x6), 15 = 5.5x8.5SEF, 16 = 5.5x8.5LEF, 17 =
8.5x11SEF, 18 = 8.5x11LEF
790-140 Fixed Size 10 of Copy Document Size
Input
17 1~50 1 = Postcard, 2 = A6SEF, 3 = A6LEF, 4 = B6SEF, 5 = B6LEF, 6 = A5SEF, 7 = A5LEF, 8 = B5SEF, 9 = B5LEF, 10
= A4SEF, 11 = A4LEF, 12 = B4SEF, 13 = A3SEF, 14 = Postcard (4x6), 15 = 5.5x8.5SEF, 16 = 5.5x8.5LEF, 17 =
8.5x11SEF, 18 = 8.5x11LEF
790-141 Fixed Size 11 of Copy Document Size
Input
18 1~50 1 = Postcard, 2 = A6SEF, 3 = A6LEF, 4 = B6SEF, 5 = B6LEF, 6 = A5SEF, 7 = A5LEF, 8 = B5SEF, 9 = B5LEF, 10
= A4SEF, 11 = A4LEF, 12 = B4SEF, 13 = A3SEF, 14 = Postcard (4x6), 15 = 5.5x8.5SEF, 16 = 5.5x8.5LEF, 17 =
8.5x11SEF, 18 = 8.5x11LEF
790-180 Default [Document Orientation] in
Copy Mode
0 0~1 0= Head to Top, 1= Head to Left
790-181 Duplex feature default setting 0 0~3 0= OFF (1 to 1 Sided), 1= 1 to 2 Sided, 2= 2 to 1 Sided,3= 2 to 2 Sided
790-182 Default Collate Mode in Copy Mode 0 0~2 0= Auto, 1= Collated, 2= Uncollated
790-183 Default Output Tray in Copy Mode 0 0~2 0= Center Tray 1= Side Tray 2= Finisher Tray * Options that are not installed cannot be selected.
790-186 Default Communication Mode 2 0~6 1= G4 Auto, 2= G3 Auto, 3= International Communication (Communication Speed is below 4800bps) 4= G3 5 =
G3 (ECM) 6 = G3 (ECM) - Forced4800
790-187 Default Density (Scan Density) 3 0~6 0= Lighter 3, 1= Lighter 2, 2= Lighter 1, 3= Normal, 4= Darker 1, 5= Darker 2, 6= Darker 3
790-188 Default Image Quality (Document
Type)
0 0~2 0=Text, 1=Photo, 2=Text/Photo
790-189 Default Resolution (Scan Resolution) 0 0~3 0= Normal, 1= High Quality (200x200), 2= High Quality (400x400), 3= High Quality (600x600)
790-190 Default Monitor Print OFF 0~1 0= OFF 1= ON
Table 20 Chain 790
Chain-Link Name Default Range Description
