Xerox DocuColor 1632 Service Manual

6/02
6-54
DC1632/2240
Prelaunch Training/Review
General Procedures and Information
790-094 Default B/W Document Type 0 0~9 0= Text, 1= Text/Photo (Print), 2= Text/Photo (Photo Paper), 3= Text/Photo (Copy Document), 4= Photo (Print),
5= Photo (Photo Paper), 6= Photo (Copy Document)
790-096 Default 4 Color/Auto Document Type 1 0~9 0= Text, 1= Text/Photo (Print), 2= Text/Photo (Photo Paper), 3= Text/Photo (Copy Document), 4= Photo (Print),
5= Photo (Photo Paper), 6= Photo (Copy Document) 7= Map, 8= Highlighted Originals, 9= Inkjet Originals
790-097 Default Background Color Removal 1 0~1 0= OFF, 1= ON
790-098 Default Density Adjustment 3 0~6 0= Lighter 3, 1= Lighter 2, 2= Lighter 1, 3= Normal, 4= Darker 1, 5= Darker 2, 6= Darker 3
790-100 Default Color Balance (Y= Low Den-
sity)
0 0~6 0~6= -3~3 (Lighter 3, Lighter 2, Lighter 1, Normal, Darker 1, Darker 2, Darker 3)
790-101 Default Color Balance (Y= Medium
Density)
0 0~6 0~6= -3~3 (Lighter 3, Lighter 2, Lighter 1, Normal, Darker 1, Darker 2, Darker 3)
790-102 Default Color Balance (Y= High Den-
sity)
0 0~6 0~6= -3~3 (Lighter 3, Lighter 2, Lighter 1, Normal, Darker 1, Darker 2, Darker 3)
790-103 Default Color Balance (M= Low Den-
sity)
0 0~6 0~6= -3~3 (Lighter 3, Lighter 2, Lighter 1, Normal, Darker 1, Darker 2, Darker 3)
790-104 Default Color Balance (M= Medium
Density)
0 0~6 0~6= -3~3 (Lighter 3, Lighter 2, Lighter 1, Normal, Darker 1, Darker 2, Darker 3)
790-105 Default Color Balance (M= High Den-
sity)
0 0~6 0~6= -3~3 (Lighter 3, Lighter 2, Lighter 1, Normal, Darker 1, Darker 2, Darker 3)
790-106 Default Color Balance (C= Low Den-
sity)
0 0~6 0~6= -3~3 (Lighter 3, Lighter 2, Lighter 1, Normal, Darker 1, Darker 2, Darker 3)
790-107 Default Color Balance (C= Medium
Density)
0 0~6 0~6= -3~3 (Lighter 3, Lighter 2, Lighter 1, Normal, Darker 1, Darker 2, Darker 3)
790-108 Default Color Balance (C= High Den-
sity)
0 0~6 0~6= -3~3 (Lighter 3, Lighter 2, Lighter 1, Normal, Darker 1, Darker 2, Darker 3)
790-109 Default Color Balance (K= Low Den-
sity)
0 0~6 0~6= -3~3 (Lighter 3, Lighter 2, Lighter 1, Normal, Darker 1, Darker 2, Darker 3)
790-110 Default Color Balance (K= Medium
Density)
0 0~6 0~6= -3~3 (Lighter 3, Lighter 2, Lighter 1, Normal, Darker 1, Darker 2, Darker 3)
790-111 Default Color Balance (K= High Den-
sity)
0 0~6 0~6= -3~3 (Lighter 3, Lighter 2, Lighter 1, Normal, Darker 1, Darker 2, Darker 3)
790-120 Default Color Shift 2 0~4 0= -20 Degrees, 1= -10 Degrees, 2= 0 Degrees, 3= +10 Degrees, 4= +20 Degrees
790-121 Default Color Saturation 2 0~4 0= Stronger 2 (Higher), 1= Stronger 1 (High), 2= Normal, 3= Softer 1 (Low), 4= Softer 2 (Lower)
790-122 Default Sharpness 2 0~4 0= Sharper, 1= Sharp, 2= Normal, 3= Soft, 4= Softer
790-123 Default Contrast 2 0~4 0= Stronger 2, 1= Stronger 1, 2= Normal, 3= Softer 1, 4= Softer 2
790-124 Default Center/Corner Shift Position
(Side1)
0 0~10 0= Off, 1= Center, 2= Upper Right, 3= Lower Right, 4= Upper Left, 5= Lower Left, 6= Upper Center, 7= Lower
Center, 8= Left Center, 9= Right Center
790-125 Default Center/Corner Shift Position
(Side2)
10 0~10 0= Off, 1= Center, 2= Upper Right, 3= Lower Right, 4= Upper Left, 5= Lower Left, 6= Upper Center, 7= Lower
Center, 8= Left Center, 9= Right Center, 10= Symmetry position with Side 1
790-126 Default Top and Bottom Edge Erase 5 (mm) 0~50 0 (mm)~50 (mm) increments of 1mm
790-127 Default Left and Right Edge Erase 5 (mm) 0~50 0 (mm)~50 (mm) increments of 1mm
790-128 Default Center Erase 0 (mm) 0~50 0 (mm)~50 (mm) increments of 1mm
790-129 Rotation Default Setting 1 0~2 0= Always Enabled 1= Enabled only at APS/AMS 2= Always Disabled
790-130 Image Orientation Default Setting 0 0~2 0= Auto, 1= Portrait document Left, 2= Portrait document Right
Table 20 Chain 790
Chain-Link Name Default Range Description
