6/02
6-53
DC1632/2240
General Procedures and Information
Prelaunch Training/Review
790-xxx ESS Panel Display Setting NVM List
780-068 Edge Erase Adjustment value (Side) 2.0 10~30 1.0~3.0mm (0.1mm unit)
780-069 Image Enhancement MC Setting 1 0~1 0 = OFF 1 = ON
780-072 Offset operation of Center Tray 1 0~2 0 = Offset Off 1 = Offset Per Set 2 = Offset Per Job
780-073 Offset operation of Finisher Tray 1 0~2 0 = Offset Off 1 = Offset Per Set 2 = Offset Per Job
Table 19 Chain 780
Chain-Link Name Default Range Description
Table 20 Chain 790
Chain-Link Name Default Range Description
790-001 Startup Display Setting 0 0~2 0= Features Programming Screen 1= Job Management Screen 2= Machine Status Screen
790-002 Function Setup Startup Display 1 0~3 0= Menu 1= Copy 3= Scanner
790-004 Toner Near Empty advance notification 1 0~1 0= No display 1= Display
790-050 Pre Set Tray 1 1 1~5 1= Tray 1 2= Tray 2 3= Tray 3 4= Tray 4 5= SMH
790-051 Pre Set Tray 2 2 1~5 1= Tray 1 2= Tray 2 3= Tray 3 4= Tray 4 5= SMH
790-052 Pre Set Tray 3 3 1~5 1= Tray 1 2= Tray 2 3= Tray 3 4= Tray 4 5= SMH
790-060 Pre Set Magnification 1 1 1~7 1~7= Fixed Magnification 1~7
790-061 Pre Set Magnification 2 2 1~7 1~7= Fixed Magnification 1~7
790-070 Default Tray Setting in Copy Mode 0 0~5 0 = Auto 1= Tray 1 2= Tray 2 3= Tray 3 4= Tray 4 5= SMH
790-071 Tray at Auto Cancellation 1 1= Tray 1 2= Tray 2 3= Tray 3 4= Tray 4
790-072 Default Magnification Setting in Copy
Mode
0 0~8 0=100% 1~7= Fixed Magnification 1~Fixed Magnification 7 8= Auto
790-073 Fixed Magnification 1 Setting 3 1~18 1 =25.0, 2 =35.3, 3 =50.0, 4 =57.7, 5 =61.2 6 =64.7, 7 =70.7, 8 =81.6, 9 =86.6 10 =115.4, 11 =122.5, 12
=129.4 13 =141.4, 14 =163.2, 15 =173.2 16 =200.0, 17 =282.8, 18 =400.0%
790-074 Fixed Magnification 2 Setting 7 1~18 1 =25.0, 2 =35.3, 3 =50.0, 4 =57.7, 5 =61.2 6 =64.7, 7 =70.7, 8 =81.6, 9 =86.6 10 =115.4, 11 =122.5, 12
=129.4 13 =141.4, 14 =163.2, 15 =173.2 16 =200.0, 17 =282.8, 18 =400.0%
790-075 Fixed Magnification 3 Setting 8 1~18 1 =25.0, 2 =35.3, 3 =50.0, 4 =57.7, 5 =61.2 6 =64.7, 7 =70.7, 8 =81.6, 9 =86.6 10 =115.4, 11 =122.5, 12
=129.4 13 =141.4, 14 =163.2, 15 =173.2 16 =200.0, 17 =282.8, 18 =400.0%
790-076 Fixed Magnification 4 Setting 9 1~18 1 =25.0, 2 =35.3, 3 =50.0, 4 =57.7, 5 =61.2 6 =64.7, 7 =70.7, 8 =81.6, 9 =86.6 10 =115.4, 11 =122.5, 12
=129.4 13 =141.4, 14 =163.2, 15 =173.2 16 =200.0, 17 =282.8, 18 =400.0%
790-077 Fixed Magnification 5 Setting 10 1~18 1 =25.0, 2 =35.3, 3 =50.0, 4 =57.7, 5 =61.2 6 =64.7, 7 =70.7, 8 =81.6, 9 =86.6 10 =115.4, 11 =122.5, 12
=129.4 13 =141.4, 14 =163.2, 15 =173.2 16 =200.0, 17 =282.8, 18 =400.0%
790-078 Fixed Magnification 6 Setting 11 1~18 1 =25.0, 2 =35.3, 3 =50.0, 4 =57.7, 5 =61.2 6 =64.7, 7 =70.7, 8 =81.6, 9 =86.6 10 =115.4, 11 =122.5, 12
=129.4 13 =141.4, 14 =163.2, 15 =173.2 16 =200.0, 17 =282.8, 18 =400.0%
790-079 Fixed Magnification 7 Setting 13 1~18 1 =25.0, 2 =35.3, 3 =50.0, 4 =57.7, 5 =61.2 6 =64.7, 7 =70.7, 8 =81.6, 9 =86.6 10 =115.4, 11 =122.5, 12
=129.4 13 =141.4, 14 =163.2, 15 =173.2 16 =200.0, 17 =282.8, 18 =400.0%
790-090 Default Color Mode 0 0~5 0= OFF 1= Auto 2= B/W 3= 4 Colors 4= Single Color 5= Dual Color
790-091 Default Single Color Selection 1 0~12
790-092 Default Dual Color Selection (Achro-
matic Color)
0 0~12 1~6= Fixed Registered Color 1~6 7~12= User Registered Color 1~6
790-093 Default Dual Color Selection (Chro-
matic Color)
1 0~12 1~6= Fixed Registered Color 1~6 7~12= User Registered Color 1~6
