Xerox DocuColor 1632 Service Manual

6/02
6-52
DC1632/2240
Prelaunch Training/Review
General Procedures and Information
780-026 Image Quality Control Category = Plain
Paper
0x02 0x01~0x80 0x01 = Plain Paper A (J paper/JD paper/J Coat paper/CX28lb equivalent) 0x02 = Plain Paper B (P paper/C2
paper equivalent) 0x04 = Plain Paper C (WR100/Green100 equivalent) 0x08 = Plain Paper D (4024-20lb/Askul
equivalent (Normal)) 0x10 = Plain Paper E (4024-20lb/Askul equivalent (gradation emphasis)), 0x20 = Plain
Paper F (4024-24lb equivalent (Normal)) 0x40 = Plain Paper G
780-027 Image Quality Control Category =
Recycle Paper
0x04 0x01~0x80 0x01 = Plain Paper A (J paper/JD paper/J Coat paper/CX28lb equivalent) 0x02 = Plain Paper B (P paper/C2
paper equivalent) 0x04 = Plain Paper C (WR100/Green100 equivalent) 0x08 = Plain Paper D (4024-20lb/Askul
equivalent (Normal)) 0x10 = Plain Paper E (4024-20lb/Askul equivalent (gradation emphasis)), 0x20 = Plain
Paper F (4024-24lb equivalent (Normal)) 0x40 = Plain Paper G
780-028 Image Quality Control Category = Cus-
tom Paper 1
0x02 0x01~0x80 0x01 = Plain Paper A (J paper/JD paper/J Coat paper/CX28lb equivalent) 0x02 = Plain Paper B (P paper/C2
paper equivalent) 0x04 = Plain Paper C (WR100/Green100 equivalent) 0x08 = Plain Paper D (4024-20lb/Askul
equivalent (Normal)) 0x10 = Plain Paper E (4024-20lb/Askul equivalent (gradation emphasis)), 0x20 = Plain
Paper F (4024-24lb equivalent (Normal)) 0x40 = Plain Paper G
780-029 Image Quality Control Category = Cus-
tom Paper 2
0x02 0x01~0x80 0x01 = Plain Paper A (J paper/JD paper/J Coat paper/CX28lb equivalent) 0x02 = Plain Paper B (P paper/C2
paper equivalent) 0x04 = Plain Paper C (WR100/Green100 equivalent) 0x08 = Plain Paper D (4024-20lb/Askul
equivalent (Normal)) 0x10 = Plain Paper E (4024-20lb/Askul equivalent (gradation emphasis)), 0x20 = Plain
Paper F (4024-24lb equivalent (Normal)) 0x40 = Plain Paper G
780-030 Image Quality Control Category = Cus-
tom Paper 3
0x02 0x01~0x80 0x01 = Plain Paper A (J paper/JD paper/J Coat paper/CX28lb equivalent) 0x02 = Plain Paper B (P paper/C2
paper equivalent) 0x04 = Plain Paper C (WR100/Green100 equivalent) 0x08 = Plain Paper D (4024-20lb/Askul
equivalent (Normal)) 0x10 = Plain Paper E (4024-20lb/Askul equivalent (gradation emphasis)), 0x20 = Plain
Paper F (4024-24lb equivalent (Normal)) 0x40 = Plain Paper G
780-031 Image Quality Control Category = Cus-
tom Paper 4
0x02 0x01~0x80 0x01 = Plain Paper A (J paper/JD paper/J Coat paper/CX28lb equivalent) 0x02 = Plain Paper B (P paper/C2
paper equivalent) 0x04 = Plain Paper C (WR100/Green100 equivalent) 0x08 = Plain Paper D (4024-20lb/Askul
equivalent (Normal)) 0x10 = Plain Paper E (4024-20lb/Askul equivalent (gradation emphasis)), 0x20 = Plain
Paper F (4024-24lb equivalent (Normal)) 0x40 = Plain Paper G
780-032 Image Quality Control Category = Cus-
tom Paper 5
0x02 0x01~0x80 0x01 = Plain Paper A (J paper/JD paper/J Coat paper/CX28lb equivalent) 0x02 = Plain Paper B (P paper/C2
paper equivalent) 0x04 = Plain Paper C (WR100/Green100 equivalent) 0x08 = Plain Paper D (4024-20lb/Askul
equivalent (Normal)) 0x10 = Plain Paper E (4024-20lb/Askul equivalent (gradation emphasis)), 0x20 = Plain
Paper F (4024-24lb equivalent (Normal)) 0x40 = Plain Paper G
780-050 Paper Type Priority = Bond Paper 3 0x01~0xff 1~8 = 1~8 X = 0xff 0 = X (According to priority not controlled by APS/ATS) Repetition allowed
780-051 Paper Type Priority = Plain Paper 1 0x01~0xff 1~8 = 1~8 X = 0xff 0 = X (According to priority not controlled by APS/ATS) Repetition allowed
780-052 Paper Type Priority = Recycle Paper 2 0x01~0xff 1~8 = 1~8 X = 0xff 0 = X (According to priority not controlled by APS/ATS) Repetition allowed
780-053 Paper Type Priority = Custom Paper 1 X 0x01~0xff 1~8 = 1~8 X = 0xff 0 = X (According to priority not controlled by APS/ATS) Repetition allowed
780-054 Paper Type Priority = Custom Paper 2 X 0x01~0xff 1~8 = 1~8 X = 0xff 0 = X (According to priority not controlled by APS/ATS) Repetition allowed
780-055 Paper Type Priority = Custom Paper 3 X 0x01~0xff 1~8 = 1~8 X = 0xff 0 = X (According to priority not controlled by APS/ATS) Repetition allowed
780-056 Paper Type Priority = Custom Paper 4 X 0x01~0xff 1~8 = 1~8 X = 0xff 0 = X (According to priority not controlled by APS/ATS) Repetition allowed
780-057 Paper Type Priority = Custom Paper 5 X 0x01~0xff 1~8 = 1~8 X = 0xff 0 = X (According to priority not controlled by APS/ATS) Repetition allowed
780-060 Tray 1 Priority 1 1~4 The priority follows the number; 1 is the highest priority. Repetition not allowed.
780-061 Tray 2 Priority 2 1~4 The priority follows the number; 1 is the highest priority. Repetition not allowed.
780-062 Tray 3 Priority 3 1~4 The priority follows the number; 1 is the highest priority. Repetition not allowed.
780-063 Tray 4 Priority 4 1~4 The priority follows the number; 1 is the highest priority. Repetition not allowed.
780-066 Edge Erase Adjustment value (Lead
Edge)
4.0 40~50 4.0~5.0mm (0.1mm unit)
780-067 Edge Erase Adjustment value (Trail
Edge)
2.0 20~30 2.0~3.0mm (0.1mm unit)
Table 19 Chain 780
Chain-Link Name Default Range Description
