6/02
6-51
DC1632/2240
General Procedures and Information
Prelaunch Training/Review
780-xxx ESS Print Frame Setting NVM List
770-110 DNS Auto Config. DHCP 0~1 0x10 = Manual Setting, 0x02 = DHCP
770-112 DNS Domain Name NULL [Setup Range] = DNS Domain Name (Normally, it is within 255 characters including the "." (dot) at the end which is not dis-
played)
770-120 TBD DHCP [Setup Range] = 0x10 = Manual Setting, 0x02 = DHCP
770-121 TBD 0.0.0.0 [Setup Range] = 00000000~FFFFFFFF
770-123 TBD 0.0.0.0 0x00000000~0xFF
FFFFFF
00000000~FFFFFFFF
770-130 Agent Port Enable Start Up 0~1 0 = Stop 1 = Start Up
770-131 Agent Transport Flag UDP - 0 = both OFF, 1 = IPX, 2 = UDP, 3 = both ON
770-133 Agent Community Name NULL - JISX0201 Character Code 12 Characters (Replace to "fxSystemMgr" on the PDU) Agent Community Name 1 ~
Agent Community Name 10
770-140 EWS Port Enable Start Up 0~1 0 = Stop 1 = Start Up
770-150 Salutation Port Enable Stop 0~1 0 = Stop 1 = Start Up
770-160 MFIO Port Enable Stop 0~1 0 = Stop 1 = Start Up
770-166 HTTP Max Session 5 - 1~10
770-190 Mail Service Start/Stop 1 0~1 1 = Start Up, 0 = Stop
770-191 Address of Mail Sender NULLR [Setup Range] = Maximum 128 ASCII characters (types include alphanumerics, [@] [. (period)] [+] [-] [=] [_ (underscore)] [/] [<]
[>]). Format = username@domain.name
770-202 SMTP Mail Server IP Address 0.0.0.0 0x00000000~0xFF
FFFFFF
00000000~FFFFFFFF
Table 18 Chain 770
Chain-Link Name Default Range Description
Table 19 Chain 780
Chain-Link Name Default Range Description
780-013 Paper Type for Tray 1 22 [Setup Range] = 22 = Bond 1 = Plain Paper 14 = Recycled Paper 23~27 = Custom Paper 1~5
780-014 Paper Type for Tray 2 22 [Setup Range] = 22 = Bond 1 = Plain Paper 14 = Recycled Paper 23~27 = Custom Paper 1~5
780-015 Paper Type for Tray 3 22 [Setup Range] = 22 = Bond 1 = Plain Paper 14 = Recycled Paper 23~27 = Custom Paper 1~5
780-016 Paper Type for Tray 4 22 [Setup Range] = 22 = Bond 1 = Plain Paper 14 = Recycled Paper 23~27 = Custom Paper 1~5
780-018 Paper Type for SMH 22 [Setup Range] = 22 = Bond 1 = Plain Paper 14 = Recycled Paper 23~27 = Custom Paper 1~5
780-019 User Define = Name of Types 1 Paper NULL [Setup Range] = Maximum 24 characters of ASCII (M/N)
780-020 User Define = Name of Types 2 Paper NULL [Setup Range] = Maximum 24 characters of ASCII (M/N)
780-021 User Define = Name of Types 3 Paper NULL [Setup Range] = Maximum 24 characters of ASCII (M/N)
780-022 User Define = Name of Types 4 Paper NULL [Setup Range] = Maximum 24 characters of ASCII (M/N)
780-023 User Define = Name of Types 5 Paper NULL [Setup Range] = Maximum 24 characters of ASCII (M/N)
780-025 Image Quality Control Category =
Bond paper
0x02 0x01~0x80 0x01 = Plain Paper A (J paper/JD paper/J Coat paper/CX28lb equivalent) 0x02 = Plain Paper B (P paper/C2
paper equivalent) 0x04 = Plain Paper C (WR100/Green100 equivalent) 0x08 = Plain Paper D (4024-20lb/Askul
equivalent (Normal)) 0x10 = Plain Paper E (4024-20lb/Askul equivalent (gradation emphasis)), 0x20 = Plain
Paper F (4024-24lb equivalent (Normal)) 0x40 = Plain Paper G
