Page #821 background image
6/02
6-57
DC1632/2240
General Procedures and Information
Prelaunch Training/Review
790-240 Fixed Size 10 of Scan Document Size
Input
5x7
(Photo
2L Size)
1~50 1 = Postcard, 2 = A6SEF, 3 = A6LEF, 4 = B6SEF, 5 = B6LEF, 6 = A5SEF, 7 = A5LEF, 8 = B5SEF, 9 = B5LEF, 10
= A4SEF, 11 = A4LEF, 12 = B4SEF, 13 = A3SEF, 14 = Postcard (4x6), 15 = 5.5x8.5SEF, 16 = 5.5x8.5LEF, 17 =
8.5x11SEF, 18 = 8.5x11LEF
790-241 Fixed Size 11 of Scan Document Size
Input
3.5x5
(Photo L
Size)
1~50 1 = Postcard, 2 = A6SEF, 3 = A6LEF, 4 = B6SEF, 5 = B6LEF, 6 = A5SEF, 7 = A5LEF, 8 = B5SEF, 9 = B5LEF, 10
= A4SEF, 11 = A4LEF, 12 = B4SEF, 13 = A3SEF, 14 = Postcard (4x6), 15 = 5.5x8.5SEF, 16 = 5.5x8.5LEF, 17 =
8.5x11SEF, 18 = 8.5x11LEF
790-250 Fixed Size 1 Fast Scan NULL 15~297 15~297mm
790-251 Fixed Size 1 Slow Scan NULL 15~432 15~432mm
790-252 Fixed Size 2 Fast Scan NULL 15~297 15~297mm
790-253 Fixed Size 2 Slow Scan NULL 15~432 15~432mm
790-254 Fixed Size 3 Fast Scan NULL 15~297 15~297mm
790-255 Fixed Size 3 Slow Scan NULL 15~432 15~432mm
790-256 Fixed Size 4 Fast Scan NULL 15~297 15~297mm
790-257 Fixed Size 4 Slow Scan NULL 15~432 15~432mm
790-258 Fixed Size 5 Fast Scan NULL 15~297 15~297mm
790-259 Fixed Size 5 Slow Scan NULL 15~432 15~432mm
790-260 Fixed Size 6 Fast Scan NULL 15~297 15~297mm
790-261 Fixed Size 6 Slow Scan NULL 15~432 15~432mm
790-262 Fixed Size 7 Fast Scan NULL 15~297 15~297mm
790-263 Fixed Size 7 Slow Scan NULL 15~432 15~432mm
790-264 Fixed Size 8 Fast Scan NULL 15~297 15~297mm
790-265 Fixed Size 8 Slow Scan NULL 15~432 15~432mm
790-266 Fixed Size 9 Fast Scan NULL 15~297 15~297mm
790-267 Fixed Size 9 Slow Scan NULL 15~432 15~432mm
790-268 Fixed Size 10 Fast Scan NULL 15~297 15~297mm
790-269 Fixed Size 10 Slow Scan NULL 15~432 15~432mm
790-270 Fixed Size 11 Fast Scan NULL 15~297 15~297mm
790-271 Fixed Size 11 Slow Scan NULL 15~432 15~432mm
790-272 Default [Document Orientation] in
SCAN Mode
0 0~1 0= Head to Top, 1= Head to Left
790-273 Default 1 setting of SCAN Fixed mag-
nification
50.0% 0~18 1 =25.0, 2 =35.3, 3 =50.0, 4 =57.7, 5 =61.2 6 =64.7, 7 =70.7, 8 =81.6, 9 =86.6 10 =115.4, 11 =122.5, 12
=129.4 13 =141.4, 14 =163.2, 15 =173.2 16 =200.0, 17 =282.8, 18 =400.0%
790-274 Default 2 setting of SCAN Fixed mag-
nification
70.7% 0~18 1 =25.0, 2 =35.3, 3 =50.0, 4 =57.7, 5 =61.2 6 =64.7, 7 =70.7, 8 =81.6, 9 =86.6 10 =115.4, 11 =122.5, 12
=129.4 13 =141.4, 14 =163.2, 15 =173.2 16 =200.0, 17 =282.8, 18 =400.0%
790-275 Default 3 setting of SCAN Fixed mag-
nification
81.6% 0~18 1 =25.0, 2 =35.3, 3 =50.0, 4 =57.7, 5 =61.2 6 =64.7, 7 =70.7, 8 =81.6, 9 =86.6 10 =115.4, 11 =122.5, 12
=129.4 13 =141.4, 14 =163.2, 15 =173.2 16 =200.0, 17 =282.8, 18 =400.0%
790-276 Default 4 setting of SCAN Fixed mag-
nification
86.6% 0~18 1 =25.0, 2 =35.3, 3 =50.0, 4 =57.7, 5 =61.2 6 =64.7, 7 =70.7, 8 =81.6, 9 =86.6 10 =115.4, 11 =122.5, 12
=129.4 13 =141.4, 14 =163.2, 15 =173.2 16 =200.0, 17 =282.8, 18 =400.0%
790-277 Default 5 setting of SCAN Fixed mag-
nification
115.4% 0~18 1 =25.0, 2 =35.3, 3 =50.0, 4 =57.7, 5 =61.2 6 =64.7, 7 =70.7, 8 =81.6, 9 =86.6 10 =115.4, 11 =122.5, 12
=129.4 13 =141.4, 14 =163.2, 15 =173.2 16 =200.0, 17 =282.8, 18 =400.0%
790-278 Default 6 setting of SCAN Fixed mag-
nification
122.4% 0~18 1 =25.0, 2 =35.3, 3 =50.0, 4 =57.7, 5 =61.2 6 =64.7, 7 =70.7, 8 =81.6, 9 =86.6 10 =115.4, 11 =122.5, 12
=129.4 13 =141.4, 14 =163.2, 15 =173.2 16 =200.0, 17 =282.8, 18 =400.0%
Table 20 Chain 790
Chain-Link Name Default Range Description
