Xerox DocuColor 1632 Service Manual

6/02
6-58
DC1632/2240
Prelaunch Training/Review
General Procedures and Information
800-xxx ESS Print Service Setting
790-279 Default 7 setting of SCAN Fixed mag-
nification
141.4% 0~18 1 =25.0, 2 =35.3, 3 =50.0, 4 =57.7, 5 =61.2 6 =64.7, 7 =70.7, 8 =81.6, 9 =86.6 10 =115.4, 11 =122.5, 12
=129.4 13 =141.4, 14 =163.2, 15 =173.2 16 =200.0, 17 =282.8, 18 =400.0%
790-280 Output Size 1 A3SEF 1~50 1 = Postcard, 2 = A6SEF, 3 = A6LEF, 4 = B6SEF, 5 = B6LEF, 6 = A5SEF, 7 = A5LEF, 8 = B5SEF, 9 = B5LEF, 10
= A4SEF, 11 = A4LEF, 12 = B4SEF, 13 = A3SEF, 14 = Postcard (4x6), 15 = 5.5x8.5SEF, 16 = 5.5x8.5LEF, 17 =
8.5x11SEF, 18 = 8.5x11LEF
790-281 Output Size 2 A4SEF 1~50 1 = Postcard, 2 = A6SEF, 3 = A6LEF, 4 = B6SEF, 5 = B6LEF, 6 = A5SEF, 7 = A5LEF, 8 = B5SEF, 9 = B5LEF, 10
= A4SEF, 11 = A4LEF, 12 = B4SEF, 13 = A3SEF, 14 = Postcard (4x6), 15 = 5.5x8.5SEF, 16 = 5.5x8.5LEF, 17 =
8.5x11SEF, 18 = 8.5x11LEF
790-282 Output Size 3 A4LEF 1~50 1 = Postcard, 2 = A6SEF, 3 = A6LEF, 4 = B6SEF, 5 = B6LEF, 6 = A5SEF, 7 = A5LEF, 8 = B5SEF, 9 = B5LEF, 10
= A4SEF, 11 = A4LEF, 12 = B4SEF, 13 = A3SEF, 14 = Postcard (4x6), 15 = 5.5x8.5SEF, 16 = 5.5x8.5LEF, 17 =
8.5x11SEF, 18 = 8.5x11LEF
790-283 Output Size 4 A5SEF 1~50 1 = Postcard, 2 = A6SEF, 3 = A6LEF, 4 = B6SEF, 5 = B6LEF, 6 = A5SEF, 7 = A5LEF, 8 = B5SEF, 9 = B5LEF, 10
= A4SEF, 11 = A4LEF, 12 = B4SEF, 13 = A3SEF, 14 = Postcard (4x6), 15 = 5.5x8.5SEF, 16 = 5.5x8.5LEF, 17 =
8.5x11SEF, 18 = 8.5x11LEF
790-284 Output Size 5 B4SEF 1~50 1 = Postcard, 2 = A6SEF, 3 = A6LEF, 4 = B6SEF, 5 = B6LEF, 6 = A5SEF, 7 = A5LEF, 8 = B5SEF, 9 = B5LEF, 10
= A4SEF, 11 = A4LEF, 12 = B4SEF, 13 = A3SEF, 14 = Postcard (4x6), 15 = 5.5x8.5SEF, 16 = 5.5x8.5LEF, 17 =
8.5x11SEF, 18 = 8.5x11LEF
790-285 Output Size 6 B5SEF 1~50 1 = Postcard, 2 = A6SEF, 3 = A6LEF, 4 = B6SEF, 5 = B6LEF, 6 = A5SEF, 7 = A5LEF, 8 = B5SEF, 9 = B5LEF, 10
= A4SEF, 11 = A4LEF, 12 = B4SEF, 13 = A3SEF, 14 = Postcard (4x6), 15 = 5.5x8.5SEF, 16 = 5.5x8.5LEF, 17 =
8.5x11SEF, 18 = 8.5x11LEF
790-286 Output Size 7 11x17SE
F
1~50 1 = Postcard, 2 = A6SEF, 3 = A6LEF, 4 = B6SEF, 5 = B6LEF, 6 = A5SEF, 7 = A5LEF, 8 = B5SEF, 9 = B5LEF, 10
= A4SEF, 11 = A4LEF, 12 = B4SEF, 13 = A3SEF, 14 = Postcard (4x6), 15 = 5.5x8.5SEF, 16 = 5.5x8.5LEF, 17 =
8.5x11SEF, 18 = 8.5x11LEF
790-287 Output Size 8 8.5x11S
EF
1~50 1 = Postcard, 2 = A6SEF, 3 = A6LEF, 4 = B6SEF, 5 = B6LEF, 6 = A5SEF, 7 = A5LEF, 8 = B5SEF, 9 = B5LEF, 10
= A4SEF, 11 = A4LEF, 12 = B4SEF, 13 = A3SEF, 14 = Postcard (4x6), 15 = 5.5x8.5SEF, 16 = 5.5x8.5LEF, 17 =
8.5x11SEF, 18 = 8.5x11LEF
790-288 Default Background Color Removal in
SCAN Mode
0 0~1 0= OFF, 1= ON
790-290 Basic Screen Preset Magnification 1 2 1~7 1~7= Fixed Magnification 1~7
790-291 Basic Screen Preset Magnification 2 4 1~7 1~7= Fixed Magnification 1~7
790-292 Basic Screen Preset Magnification 3 7 1~7 1~7= Fixed Magnification 1~7
Table 20 Chain 790
Chain-Link Name Default Range Description
Table 21 Chain 800
Chain/Link Name Default Range Description
800-001 APS Job Recovery Method 6 - 6 = Displays add paper (SPS Off), 5 = Uses a larger paper size (no adjustment), 2 = Uses a nearest paper
size (no adjustment), 7 = Only Oceans2 uses a substitution. (Abort) =
800-006 Expand Print Mode Normal - 1 = Normal, 2 = Expand
