Xerox DocuColor 1632 Service Manual

6/02
6-71
DC1632/2240
dC330
General Procedures and Information
Prelaunch Training/Review
001-306 INTLK_3 High when Open is detected. ON: High
004-100 Belt Home Sensor [Operation Description]: IBT is not at Home Posi-
tion. Open circuit. It is necessary to operate IBT
5V ON. ON: High
004-101 Drum Motor YMC Fail Detec-
tion
PR (Drum) Motor YMC Failure ON: High
004-102 Drum Motor K Fail Detection PR (Drum) Motor K Failure ON: High
004-200 FAN_LOCK_FAIL Fan rotation is stopped ON: FAIL
005-102 Document Sensor No paper detected by Document Sensor ON:
High
005-110 Regi Sensor (DADF) Paper detected by Regi Sensor ON: Low
005-115 Exit Sensor Paper detected by Exit Sensor ON: Low
005-119 Dup Sensor Paper detected by Dup Sensor ON: Low
005-150 #1 Size Sensor No paper detected by #1 Size Sensor ON: High
005-151 #2 Size Sensor No paper detected by #2 Size Sensor ON: High
005-201 Exchange from IISS Document Exchange InstructiON. ON from IISS
ON: Low
005-300 Platen I/L Switch Platen Cover Open ON: High
005-301 Top Cover I/L Switch Top Cover Inter Lock Open ON: High
006-160 Polygon Motor Ready Signal Regular rotation of Polygon Motor ON: Low
006-201 Sheet Abort Document Regist ON: Low
006-212 IIT Regi Sensor Deactuation of Regi Sensor ON: Low
006-240 ADF Exist DADF is not installed ON: High
006-251 APS Sensor1 Document is detected ON: APS SNR1: Low, APS
ON: High
006-253 APS Sensor3 Document is detected ON: APS SNR3: Low, APS
ON: High
006-272 PM-0 Flash Memory writing is not in progress ON:
Inside PWBA
006-281 IPS Fan Fail High when FAN failure is detected. ON: High
006-300 Platen I/L Switch Low when Platen closed. ON: Low
006-301 Angle Sensor Low when Platen closed. ON: Low
007-100 #1Tray Size SW1 ON: AN value
007-101 #1Tray Size SW2 ON: AN value
007-102 #1Tray Size SW3 ON: AN value
007-103 #1Tray Size SW4 ON: AN value
007-104 #2Tray Size SW1 ON: AN value
007-105 #2Tray Size SW2 ON: AN value
007-106 #2Tray Size SW3 ON: AN value
007-107 #2Tray Size SW4 ON: AN value
007-108 #3Tray Size SW1 ON: AN value
007-109 #3Tray Size SW2 ON: AN value
Table 1 Input Component Control Codes
Code Name Description
007-110 #3Tray Size SW3 ON: AN value
007-111 #3Tray Size SW4 ON: AN value
007-112 #4Tray Size SW1 ON: AN value
007-113 #4Tray Size SW2 ON: AN value
007-114 #4Tray Size SW3 ON: AN value
007-115 #4Tray Size SW4 ON: AN value
007-116 #1Level Sensor Lift Up ON: High
007-117 #2Level Sensor Lift Up ON: High
007-118 #3Level Sensor Lift Up ON: High
007-119 #4Level Sensor Lift Up ON: High
007-120 #1Nopaper Sensor No paper ON: High
007-121 #2Nopaper Sensor No paper ON: High
007-122 #3Nopaper Sensor No paper ON: High
007-123 #4Nopaper Sensor No paper ON: High
007-125 SMH No paper Sensor No paper ON: High
007-128 Face Up Tray Detect Low when Tray is installed ON: Low
008-100 #1Feed Out Sensor Paper detected ON: High
008-102 #3Feed Out Sensor Paper detected ON: High
008-103 #4Feed Out Sensor Paper detected ON: High
008-104 Regi Sensor No paperON: Low
008-105 Dup Wait Sensor Paper detected ON: High
008-106 T/A Sensor Paper detected ON: High
008-107 TTM Path Sensor1 Paper detected
008-108 TTM Path Sensor2 Paper detected
008-109 OHP Sensor#L ON: Low
008-110 OHP Sensor#R ON: Low
008-300 DUP Open Switch ON: High
009-101 Toner_Y New CRU Connection of color is open (The CRU in
use is present, or it is not present) ON: Low=new,
High=old
009-102 Toner_M New CRU Connection of color is open (The CRU in
use is present, or it is not present) ON: Low=new,
High=old
009-103 Toner_C New CRU Connection of color is open (The CRU in
use is present, or it is not present) ON: Low=new,
High=old
009-104 Toner_K New CRU Connection of color is open (The CRU in
use is present, or it is not present) ON: Low=new,
High=old
009-150 TNR FULL SNR ON: High
009-151 #Y_CRU detect CRU is installed
009-152 #M_CRU detect CRU is installed
Table 1 Input Component Control Codes
Code Name Description
