Xerox DocuColor 1632 Service Manual

6/02
6-76
DC1632/2240
dC330
Prelaunch Training/Review
General Procedures and Information
012-032 Eject Clamp Low
Down
Turns OFF automatically at 702pulses after
the Eject Home Snr detected Home Posi-
tion.
12-30, 12-31,
12-33, 12-34,
12-41
012-033 Eject Clamp Mid-
dle Down
Turns OFF automatically at 365pulses after
the Eject Home Snr detected Home Posi-
tion.
12-30, 12-31,
12-32, 12-34,
12-41
012-034 Eject Clamp UP Turns OFF automatically at 46pulses after
the Eject Home Snr detected Home Posi-
tion.
12-30, 12-31,
12-32, 12-33,
12-41
012-040 Set Clamp Paddle
Solenoid
Turns OFF automatically after 1000msec. 12-41
012-041 Set Clamp Paddle
Rev
Turns OFF automatically at Mot: 583pulses
and Sol: 200msec.
12-30, 12-31,
12-32, 12-33,
12-34, 12-40
012-050 Stacker Motor UP
On/Off
Turns OFF automatically after 500msec. 12-51
012-051 Stacker Motor
Down On/Off
[Operation Description]: 12-50
012-060 H-Tra Gate In Sole-
noid Open
Turns OFF automatically after 200msec. 12-61
012-061 H-Tra Gate In Sole-
noid Close
Turns OFF automatically after 200msec. 12-60
012-070 Decurler Cam
Clutch On
Turns OFF automatically after 1000msec. 12-71
012-071 Decurler Penetra-
tion Change
Turns OFF automatically after the Decurler
Home Snr detected On. (Stops when the
Home Snr detected ON -> OFF or OFF ->
ON by turning ON Decurler Cam Clutch
500ms after driving the Main Drive Motor.)
12-1, 12-70
012-080 Stapler Move Motor
High Front On/Off
Turns OFF automatically at 250pulses. 12-81, 12-82,
12-83
012-081 Stapler Move Motor
Low Font On/Off
Turns OFF automatically at 250pulses. 12-80, 12-82,
12-83
012-082 Stapler Move Motor
High Rear On/Off
Turns OFF automatically at 250pulses. 12-80, 12-81,
12-83
012-083 Stapler Move Motor
Low Rear On/Off
Turns OFF automatically at 250pulses. 12-80, 12-81,
12-82
012-091 Front Tamper
Motor Low Front
On/Off
Turns OFF automatically at 100pulses. 12-92, 12-93,
12-94, 12-95,
12-96
012-092 Front Tamper
Motor Middle Front
On/Off
Turns OFF automatically at 100pulses. 12-91, 12-93,
12-94, 12-95,
12-96
Table 2 Output Component Control Codes
Code Name Description Conflicts
012-093 Front Tamper
Motor High Front
On/Off
Turns OFF automatically at 100pulses. 12-91, 12-92,
12-94, 12-95,
12-96
012-094 Front Tamper
Motor Low Rear
On/Off
Turns OFF automatically at 100pulses. 12-91, 12-92,
12-93, 12-95,
12-96
012-095 Front Tamper
Motor Middle Rear
On/Off
Turns OFF automatically at 100pulses. 12-91, 12-92,
12-93, 12-94,
12-96
012-096 Front Tamper
Motor High Rear
On/Off
Turns OFF automatically at 100pulses. 12-91, 12-92,
12-93, 12-94,
12-95
Table 2 Output Component Control Codes
Code Name Description Conflicts
