Xerox DocuColor 1632 Service Manual

6/02
6-75
DC1632/2240
dC330
General Procedures and Information
Prelaunch Training/Review
009-026 #Y_BCR DC High voltage output value of BCR DC_Y.
ON: PWM
9-30
009-027 #M_BCR DC High voltage output value of BCR DC_M.
ON: PWM
9-31
009-028 #C_BCR DC High voltage output value of BCR DC_C.
ON: PWM
9-32
009-029 #K_BCR DC High voltage output value of BCR DC_K.
ON: PWM
9-33
009-030 #Y_BCR AC High voltage output value of BCR AC_Y.
ON: PWM
9-26
009-031 #M_BCR AC High voltage output value of BCR AC_M 9-27
009-032 #C_BCR AC High voltage output value of BCR AC_C 9-28
009-033 #K_BCR AC High voltage output value of BCR AC_K 9-29
009-034 [PSW Display] AGT
MOT
AGITATOR MOT ON
009-035 CRUM PWR Power ON of CRUM-YMCK
009-038 BCR ACDC K CHG [Operation Description]: DEVE_AC_K
changes at connector terminals trailing.
009-039 BCRAC Clock Frequency signal common to BCR AC All
Colors.
009-040 ROS Shutter Close ROS Shutter: Rotates in Close direction
(Brush: Contact direction).
9-41
009-041 ROS Shutter Open ROS Shutter: Rotates in Open direction
(Brush: Retract direction). ON: HHH
9-40
009-042 #K_Erase Lamp
104mm/s
K ERASE LAMP lit. 9-43, 9-44
009-043 #K_Erase Lamp
52mm/s
Not in use 9-42, 9-44
009-044 #K_Erase Lamp
194mm/s
Not in use 9-42, 9-43
009-045 #YMC_Erase Lamp
104mm/s
YMC ERASE LAMP lit. 9-46
009-046 #YMC_Erase Lamp
52mm/s
Not in use 9-45
009-051 2nd BTR Contact Driving of BTR2RETMOT. Turns OFF
800ms after the Retract SNR detected the
Contact Position (High).
-
009-052 2nd BTR Retract Turns OFF 60ms after the Retract SNR
detected the Retract Position (Low).
-
009-053 De Tack Saw HV Turn on DTS HV. -
009-054 1st BTR Contact Turns OFF 100ms after the Retract SNR
detected the Contact Position (High).
-
009-055 1st BTR Retract Turns OFF 100ms after the Retract SNR
detected the Retract Position (Low).
-
Table 2 Output Component Control Codes
Code Name Description Conflicts
009-076 Specular reflection
LED
When the Specular Reflection LED of ADC
SNR turns ON and YMC density is
detected.
-
009-077 Diffusion reflection
LED
When the Diffusion Reflection LED of ADC
SNR turns ON and K density is detected.
-
009-078 ADC Sensor Shut-
ter Open
Turns OFF automatically after 100msec. 9-79
009-079 ADC Sensor Shut-
ter Close
Turns OFF automatically after 100msec. 9-78
009-080 ATC Sensor 5V ON 5V Power supply to ATC SNR. -
010-001 OCT Motor (CW) Turns ON forward and turns OFF automati-
cally at 150msec.
010-002
010-002 OCT Motor (CCW) Turns ON reverse and turns OFF automati-
cally at 150msec.
010-001
012-001 Main Drive Motor
On/Off
[Operation Description]: 12-71
012-010 Rear Tamper Motor
Low Front On/Off
Turns OFF automatically after 100pulses. 12-11, 12-12,
12-13, 12-14,
12-15
012-011 Rear Tamper Motor
Middle Front On/Off
Turns OFF automatically after 100pulses. 12-10, 12-12,
12-13, 12-14,
12-15
012-012 Rear Tamper Motor
High Front On/Off
Turns OFF automatically after 100pulses. 12-10, 12-11,
12-13, 12-14,
12-15
012-013 Rear Tamper Motor
Low Rear On/Off
Turns OFF automatically after 100pulses. 12-10, 12-11,
12-12, 12-14,
12-15
012-014 Rear Tamper Motor
Middle Rear On/Off
Turns OFF automatically after 100pulses. 12-10, 12-11,
12-12, 12-13,
12-15
012-015 Rear Tamper Motor
High Rear On/Off
Turns OFF automatically after 100pulses. 12-10, 12-11,
12-12, 12-13,
12-14
012-020 Staple Motor Close
On/Off
Stops at Home Position. 12-21
012-021 Stapler Motor
Reverse
Turns OFF automatically after 110msec. 12-20
012-030 Eject Motor FOR-
WARD On/Off
Turns OFF automatically after 2000pulses. 12-31, 12-32,
12-33, 12-34,
12-41
012-031 Eject Motor
Reverse On/Off
Turns OFF automatically after 2000pulses. 12-30, 12-32,
12-33, 12-34,
12-4
Table 2 Output Component Control Codes
Code Name Description Conflicts
