DC1632/2240
dC612
Prelaunch Training/Review
General Procedures and Information
37 VIPER Fixed Pattern
Output/BW Binary
(For separating troubles) Connection between IPS-Controller CHK Entire
2dot width Horizontal Ladder Pattern.
For development.
Determine the defect locations when IPS defect and ASIC poor
installation etc. has occurred.
IPS
38 VIPER Fixed Pattern
Output/4C Binary
(For separating troubles) Entire 2dot width Horizontal Ladder Pattern. For development.
Determine the defect locations when IPS defect and ASIC poor
installation etc. has occurred.
IPS
39 TAG Fixed Binary
COPY-1
(For development) TAG='0' Fixed COPY. For development.
Determine the defect locations when IPS defect and ASIC poor
installation etc. has occurred.
IPS
40 TAG Fixed Binary
COPY-2
(For development) TAG='1' Fixed COPY. For development.
Determine the defect locations when IPS defect and ASIC poor
installation etc. has occurred.
IPS
Table 1 Test Patterns
Patte
rn # Pattern Name Overview Purpose Location
To Next Page
