TRAFFIC WITH POLICING
Figure 46: Data Traffic with Policing
The diagram above depicts the traffic flow after implementing Policing. Here, the
packets exceeding the available bandwidth are all dropped. This provides for a
decent flow of traffic.
128
64
128
110
128
80
90
Traffic With Policing
Arrival Rate in kb
Ti me in sec
Available bandwidth = 128 kbps
