Alcatel-Lucent OmniAccess 5740 Cli Configuration Guide

Layer 2 Switching Configuration
Except on the first page, right running head:
Heading1 or Heading1NewPage text (automatic)
177
Alcatel-Lucent
Beta Beta
OmniAccess 5740 Unified Services Gateway CLI Configuration Guide
CHAPTER 6 LAYER 2 SWITCHING CONFIGURATION
This chapter covers the commands used to configure switching on the Layer 2
(L2) cards in the OmniAccess 5740 USG. It provides a broad overview on the L2
GE commands with an expansive outlook on VLAN support consisting of Access
ports, Trunk ports and Hybrid ports.
The “Switching Overview” section serves as an additional information on L2
switching. You can skip this section, and directly go to the configuration details:
“L2 Switching Configuration”. Refer to the “Alcatel-Lucent Specific Overview on
Switching” for Alcatel-Lucent specific features.
Basic scenarios using switching on OmniAccess 5740 USG is given in the last
section. You can refer to this section for getting an in-depth knowledge of
configuring OmniAccess 5740 USG on a real-time system “Switching
Configuration using OmniAccess 5740 USG”.
CHAPTER CONVENTIONS
Acronym Description
CM Configuration Mode - ALU (config)#
ICM Interface Configuration Mode - ALU (config-interface name)#
SUM Super User Mode - ALU#

Alcatel-Lucent OmniAccess 5740 Specifications

General

Brand	Alcatel-Lucent
Model	OmniAccess 5740
Category	Gateway
Language	English
