LFI Configuration on FR
Except on the first page, right running head:
Heading1 or Heading1NewPage text (automatic)
457
Alcatel-Lucent
Beta Beta
OmniAccess 5740 Unified Services Gateway CLI Configuration Guide
LFI - FR CONFIGURATION STEPS
This section lists the commands for LFI configuration on FR.
Note: Configuring channelized serial interface on T1 or E1 controller and configuring FR
interface is a pre-requisite to LFI configuration on a FR interface.
The following FR configuration commands are shown for a T1 interface as an
example. The steps are similar for configuration of FR on an E1 interface.
For more details on T1 or an E1 controller configuration, refer to the “T1E1 Line Card”
chapter, and refer to “Frame Relay” for FR configuration.
Step 1: Enter Configuration Mode
ALU# configure terminal
ALU(config)#
Step 2: Set the controller mode to T1
ALU(config)# card type T1 <slot>
ALU(config)#
Step 3: Configure T1 Controller
ALU(config)# controller T1 <slot/port>
ALU(config-controller T1)#
Step 4: Configure the channel-group on the controller before entering the
Interface Configuration Mode. This command creates a channel-group that forms
a channelized serial interface.
ALU(config-controller T1)# channel group <0-23>
timeslots <1-24> speed [56K|64K]
Note: Creation of a channel-group is a pre-requisite for configuring a Serial Interface on a T1
or an E1 controller.
Step 5: Administratively bring up the controller.
ALU(config-controller T1)# no shutdown
Step 6: Exit from the controller mode
ALU(config-controller T1)# exit
ALU(config)#
