Frame Relay
Except on the first page, right running head:
Heading1 or Heading1NewPage text (automatic)
313
Alcatel-Lucent
Beta Beta
OmniAccess 5740 Unified Services Gateway CLI Configuration Guide
CHAPTER 14 FRAME RELAY
This chapter includes the commands for configuring Frame Relay (FR)
encapsulation on a T1 or E1 interface or a Serial (V.35/X.21) interface. You are
required to refer to the “T1E1 Line Card” and “Universal Serial Port (USP) Line
Card” chapters before proceeding to this.
This chapter includes instructions for configuring Frame Relay Local Management
Interface and Data-link Connection Identifiers on an interface/sub-interface
through the CLI. For instructions on using the FR commands and descriptions on
each of their parameters with the corresponding default values for each, refer to
the OmniAccess 5740 Unified Services Gateway CLI Command Reference
Guide.
This chapter is divided into the following sections:
“Frame Relay Overview”
“Frame Relay Configuration”
The overview section serves only as an additional information on the FR protocol.
You can skip this section and directly proceed to “Frame Relay Configuration”
section.
CHAPTER CONVENTIONS
Acronym Description
CM Configuration Mode - ALU (config)#
DCE Data Circuit-Terminating Equipment
DLCI Data-link Connection Identifier
DTE Data Terminal Equipment
ICM Interface Configuration Mode - ALU (config-interface name)#
LMI Local Management Interface
S-ICM Sub-Interface Configuration Mode - ALU (config-subif serial slot/
port:channel.subchannel)#
SUM Super User Mode - ALU#
