IRB Configuration
Except on the first page, right running head:
Heading1 or Heading1NewPage text (automatic)
217
Alcatel-Lucent
Beta Beta
OmniAccess 5740 Unified Services Gateway CLI Configuration Guide
IRB CONFIGURATION
The following section details the configuration steps and commands to configure
IRB on the OmniAccess 5740 USG.
IRB CONFIGURATION STEPS
Step 1: Configure the VLAN interface. This could also be for VLAN 1. See “To
Configure VLAN Interface”
Step 2: Attach the VLAN to one or more switchports (through the CLI commands
for access, trunk and hybrid ports).
(Refer chapter on switching “Layer 2 Switching Configuration” for a detailed
insight on the VLAN commands)
Step 3: Configure IP address, and attach policies such as Filter, IDS, etc., on the
VLAN interface (through known CLI commands for other services).
Note: - A given VLAN interface for IRB can be used only on the 8 ports of the same L2-GE
card.
- The IRB VLANs cannot be configured on the Service Engine ports.
