L2 SWITCHING CONFIGURATION
Refer to the following steps to enable switching on the L2 card in the OmniAccess
5740 USG.
L2 SWITCHING CONFIGURATION STEPS
The following commands enable switching on the L2 card in the OmniAccess
5740 USG.
Step 1: Enter Configuration Mode.
ALU# configure terminal
ALU(config)#
Step 2: Configure a L2 interface. See “To Configure an L2 Interface”
Step 3: Administratively bring up the interface. See “To Administratively Bring Up/
Down the L2 Interface”
Step 4: L2 interface can be configured for four modes of operation. Following are
the steps to configure L2 to operate in either Pure Bridging Mode, Access, Trunk
or Hybrid mode. These steps are optional.
• Configure L2 interface to operate in Pure Bridging Mode:
Step 1: Configure L2 interface to Pure Bridging mode by using “no
switchport mode” command. See “To Configure Mode for the L2 Interface”
(If no access VLAN is configured)
OR
• Configure L2 interface to operate in Access Mode:
Step 1: Configure L2 interface to Access mode by using “no switchport
mode” command. See “To Configure Mode for the L2 Interface” (if Trunk/
Hybrid mode is already configured)
Step 2: Configure VLAN for Access mode. See “To Configure VLAN for
Access Mode”
OR
