PBR CONFIGURATION COMMANDS
The following steps are used to configure a PBR on the OmniAccess 5740 USG.
T
O CONFIGURE AN IP POLICY
EXAMPLE
ALU(config)# ip-policy pbr1
ALU(config-ip-policy-pbr1)#
ALU(config)# no ip-policy pbr1
T
O CONFIGURE A RULE FOR AN IP POLICY
This command specifies the match conditions and forwarding action.
• Rule can have multiple match-lists along with the option of any/all.
• Rule can also have one match-list with NOT option. Match-list with NOT option
can only be specified as the last match-list and only one match-list can have NOT
option.
• The interface-name and/or next-hop shall specify the egress path of the packet.
• The 'for-us' keyword redirects the packet to the management plane of the
OmniAccess 5740 USG.
• Only one of next-hop and/or interface or for-us shall be in effect at any time.
• If the interface and next-hop are specified together, then the packet shall be
forwarded to the specified next-hop on the specified interface.
Note: When the interface option is chosen as Ethernet/VLAN, it is mandatory to specify the
next hop.
• The range for the rule is 1-65535. This rule number signifies the priority of a rule.
Command (in CM) Description
ip-policy <name> This command is used to create an IP
policy.
no ip-policy <name> [force] This command is used to delete an IP
policy. If the policy is attached to any of
the interfaces, it cannot be deleted.
The "force" keyword will automatically
detach the specified policy from
respective interfaces, and deletes the IP
policy. This command when used also
deletes all the rules configured under this
policy.
